Features:
Compact, space-saving design ideal for laboratories, clinics, hospitals, and research facilities
Vertical cylindrical chamber ensures efficient sterilization of small to medium loads
Fabricated using high-quality stainless steel for corrosion resistance, durability, and hygiene
Double-walled or triple-walled construction with efficient steam jacket for uniform heat distribution
Manual or automatic lid lifting mechanism with pressure interlock for user safety
Equipped with pressure gauge, steam release valve, safety valve, and automatic pressure cut-off
Digital or analog control panels for easy monitoring of temperature and sterilization time
Integrated water level indicator and low-water level protection system
Uniform steam penetration ensures thorough sterilization of instruments, glassware, media, and fabrics
Suitable for semi-automatic or fully automatic operation based on model configuration
S.NO. | ||||
---|---|---|---|---|
1 | DR VAC HM 3WD75 | Vertical, Triple Walled, Basic with Drying System | 400 Dia x 600 H | 75 Ltr |
2 | DR VAC HM 2W75 | Vertical, Double Walled, Basic | 400 Dia x 600 H | 75 Ltr |
3 | DR VAC HM 2W35 | Vertical, Double Walled, Basic | 300 Dia x 500 H | 35 Ltr |
S.NO. | ||||
---|---|---|---|---|
1 | DR VAC HM 3WST75 | Vertical, High Pressure, Triple Walled, Steam Storage with PLC Controlled Temperature, Low Water Cut-off, Timer,Alarm | 400 Dia x 600 H | 75 Ltr |
2 | DR VAC HM 3WS75 | Vertical, High Pressure, Triple Walled, Steam Storage with PLC Controlled Temperature, Low Water Cut-off | 400 Dia x 600 H | 75 Ltr |
Specifications:
MODEL | DR HPS LC50 | DR HPS LC 110 | DR HPS LC135 | DR HPS 16053 |
Chamber volume | 50 Ltr. | 110 Ltr. | 135 Ltr. | 160 Ltr. |
CODE
|
APPROX. CAPACITY
|
DIMENSIONS (LxBxH)
|
TRAY DIMENSIONS (LxBxH)
|
DR ACS IS01Â
|
5.5 Lit.
|
300 x 150 x 125mm
|
245 x 125 x 25mm
|
DR ACS IS02
|
12.0 Lit.
|
430 x 200 x 150mm
|
355 x 180 x 25mm
|
DR ACS IS03
|
15.0 Ut.
|
510 x 200 x 150mm
|
435 x 180 x 25mm
|
CODE
|
APPROX. CAPACITY
|
DIMENSIONS (LxBxH)
|
DR ACS IS NEE01
|
2.0 Lit
|
200 x 125 x 80mm
|
DR ACS IS NEE02
|
2.5 Lit.
|
250 x 125 x 80mm
|
DR ACS IS NEE03
|
4.5 Lit.
|
300 x 150 x 100mm
|
DR ACS IS NEE04
|
5.2 Lit.
|
350 x 150 x 100mm
|
DR ACS IS NEE05
|
6.0 Lit.
|
400 x 150 x 100mm
|
DR ACS IS NEE06
|
12.0 Lit.
|
400 x 200 x 150mm
|
DR ACS IS NEE07
|
13.5 Lit.
|
450 x 200 x 150mm
|
DR ACS IS NEE08
|
15.0 Lit.
|
500 x 200 x 150mm
|
CODE
|
APPROX. CAPACITY
|
DIMENSIONS (LxBxH)
|
DR ACS IS EE01
|
2.7 Lit.
|
200 x 125 x 115mm
|
DR ACS IS EE02
|
3.5 Lit.
|
250 x 125 x 115mm
|
DR ACS IS EE03
|
6.2 Lit.
|
300 x 150 x 140mm
|
DR ACS IS EE04
|
7.2 Lit.
|
350 x 150 x 140mm
|
DR ACS IS EE05
|
8.0 Lit.
|
400 x 150 x 140mm
|
DR ACS IS EE06
|
17.0 Lit.
|
450 x 200 x 190mm
|
DR ACS IS EE07
|
19.0 Lit.
|
500 x 200 x 190mm
|
CODE
|
APPROX. CAPACITY
|
DIMENSIONS (LxBxH)
|
DR ACS IS ETE01
|
6.0 Lit.
|
300 x 150 x 140mm
|
DR ACS IS ETE02
|
7.0 Lit.
|
350 x 150 x 140mm
|
DR ACS IS ETE03
|
8.0 Lit.
|
400 x 150 x 140mm
|
DR ACS IS ETE04
|
17.0 Lit.
|
450 x 200 x 190mm
|
DR ACS IS ETE05
|
19.0 Lit.
|
500 x 200 x 190mm
|
Model | Chamber Size | External Dimension in mm | Trays | Gross Dimension / Weight |
DR ACS DA 01 | 250 mm x 450 mm | 500 x 650 x 430 | 3 | 770 x 570 x 520 mm / 54 kg |
Model | Chamber Size | External Dimension in mm | Gross Dimension / Weight |
DR ACS DA B01 | 310 x 600 | 580 x 730 x 655 | 630 x 815 x 725 mm / 115 kg |
S.NO. | ||||
---|---|---|---|---|
1 | DR M4 CAC S150 | Horizontal Cylindrical Automatic Single Door | 400 Dia x 1200 L | 150 Ltr |
2 | DR M4 CAC D150 | Horizontal Cylindrical Automatic Double Door | 400 Dia x 1200 L | 150 Ltr |
3 | DR M4 CAC S175 | Horizontal Cylindrical Automatic Single Door | 500 Dia x 900 L | 175 Ltr |
4 | DR M4 CAC D175 | Horizontal Cylindrical Automatic Double Door | 500 Dia x 900 L | 175 Ltr |
5 | DR M4 CAC S235 | Horizontal Cylindrical Automatic Single Door | 500 Dia x 1200 L | 235 Ltr |
6 | DR M4 CAC D235 | Horizontal Cylindrical Automatic Double Door | 500 Dia x 1200 L | 235 Ltr |
7 | DR M4 CAC S340 | Horizontal Cylindrical Automatic Single Door | 600 Dia x 1200 L | 340 Ltr |
