Specifications

• Measurement Parameters: SpO₂ (Oxygen Saturation) & Pulse Rate

• SpO₂ Measurement Range: 70% – 100%

• Pulse Rate Range: 30 – 250 bpm

• Accuracy (SpO₂): ±2%

• Accuracy (Pulse Rate): ±2 bpm or ±2%

• Display Type: OLED or LED

• Power Supply: 2 × AAA batteries

• Battery Life: ~20 – 30 hours of continuous use

• Weight: Approx. 50 – 60 grams

• Operating Temperature: 5°C – 40°C (41°F – 104°F)

• Storage Temperature: -10°C – 50°C

Technical Specifications

• A/D Resolution: 10 Bit
• Lead Selection: Standard 12 Leads
• Filters: Low pass filter: 35, 100Hz , High pass filter: 0.05Hz, Notch filter 50 Hz (on/off)
• Acquisition : Auto/Manual
• Memory : Last patient
• Input impedance : >100 M ohm
• Frequency Response        0.05-100Hz
• CMRR : 100dB
• Time Constant : 3.2 sec
• Sensitivity : 5mm/mV, 10mm/mV,20mm/mV
• Leakage Current : <10 micro Ampere

Technical Specifications

• Storage Space: Three spacious drawers to hold essential anesthesia kit and accessories.
• Castors: Large roller bearing anti-static castors with front brakes.
• Electronic gas mixing with electronic Hypoxia guard.
• Audio Visual alarm for failure.
• Electronic and mechanical Flush 30-70 Lpm Flow.
• System pressure relief at 125 cm.
• Cylinder Yokes: Color coded gas specific (pin indexed) yokes with sliding stainless steel clamping bars for easy handling.
• Holding 1 (One) each for and , 5 Ltr water capacity cylinders.
• Non-return / Pressure Relief Valve: Minimises risk of back flow of gases, blows off when pressure exceeds 125 cm.
• Oxygen Flush: Electronic and mechanical flush 30-70 LPM flow.
• Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22 & 15 mm connections.
• Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets one each for and Air.
• I n c a s e o f drop in piped gas pressure the pin index cylinders take over automatically.
• Hypoxia Guard: Electronic/ Digital Hypoxia guard.
• Gas Mixing: Electronic flowmeter for the graphical representation of and Air.
• Selectatec Brackets: Twin Selectatec Block.
• Breathing Circuits: Bains Circuit & Circle Absorber Y-Circuit provided as standard.
