Manual one-function hospital bed with backrest elevation
ABS molded head and foot panels, detachable for easy cleaning and emergency access
Two-section perforated mattress platform for ventilation and patient comfort
High-quality CRCA steel frame with durable epoxy powder coating
Smooth crank mechanism with foldable handle for backrest adjustment
Collapsible side rails for added patient safety
Mounted on four castors for easy movement; two with brakes
Suitable for general wards, patient rooms, and post-operative care
Provision for IV pole and drainage bag holders included
Backrest Adjustment: 0° – 75°
Platform Type: Two-section perforated steel
Frame Material:Â steel with epoxy powder coating
Head & Foot Panels: ABS, detachable and locking
Side Rails: Collapsible, aluminum or ABS
Castors: 125 mm diameter, 2 with brakes
Crank System: Single manual crank with foldable handle
Safe Working Load: 180 – 200 kg
Finish: Pre-treated and epoxy powder coated
Included Accessories: IV pole socket, drainage bag hooks, mattress retainers
Height Adjustment Range (Hi-Lo): 450 mm – 750 mm
Backrest Angle: 0° – 75° (manual crank)
Knee Rest Angle: 0° – 35° (manual crank)
Trendelenburg: 0° – 12° (manual)
Reverse Trendelenburg: 0° – 12° (manual)
Platform Sections: 4-section perforated MS platform
Frame Material:Â steel with epoxy powder coating
Head & Foot Panels: ABS, detachable
Side Rails: Collapsible, aluminum or ABS
Crank System: 3 separate crank handles (backrest, knee rest, Hi-Lo)
Safe Working Load: 200 – 250 kg
Technical Specifications
Light Source: LED or Halogen
Power: AA batteries or rechargeable handle
Magnification: Otoscope – 3x; Ophthalmoscope – adjustable lens wheel
Lens Range: ±20 diopters
Case: Compact and protective with foam interior
