Manually operated ICU bed with Hi-Lo (height adjustment) function
Crank mechanism for backrest, knee rest, and height adjustments
Durable four-section perforated bed platform for ventilation and comfort
Detachable ABS head and foot panels for easy access during emergencies
Collapsible side rails for patient safety and ease of movement
Manual Trendelenburg and reverse Trendelenburg positions available
Smooth-rolling castors with individual brakes for mobility and stability
IV pole provision and drainage hooks included
Sturdy mild steel frame with epoxy powder-coated finish for corrosion resistance
Suitable for ICU, high-dependency units, and hospital wards
Height Adjustment Range (Hi-Lo): 450 mm – 750 mm
Backrest Angle: 0° – 75° (manual crank)
Knee Rest Angle: 0° – 35° (manual crank)
Trendelenburg: 0° – 12° (manual)
Reverse Trendelenburg: 0° – 12° (manual)
Platform Sections: 4-section perforated MS platform
Frame Material: CRCA steel with epoxy powder coating
Head & Foot Panels: ABS, detachable
Side Rails: Collapsible, aluminum or ABS
Crank System: 3 separate crank handles (backrest, knee rest, Hi-Lo)
Safe Working Load: 200 – 250 kg
Measurement Method: Manual
Measurement Range: 0 – 300 mmHg
Accuracy: ±2 mmHg
Graduation: 2 mmHg increments
Cuff Size: 22 – 42 cm
Bladder Material: Latex or PVC, 2-tube design
Bulb: Rubber inflation bulb with air-release valve
Valve Type: Chrome-plated screw-type
Mercury Column: Glass tube with metal scale backing
Base Material: Powder-coated metal or ABS plastic
Weight: 2.5 – 3 kg
Operating Temperature: 10°C – 40°C
Storage Temperature: -10°C – 50°C
Measurement Parameters:
– SpO₂ (Oxygen Saturation): 0% – 100%
– Pulse Rate: 30 – 250 bpm
SpO₂ Accuracy: ±2% (for 70% – 100% range)
Pulse Rate Accuracy: ±2 bpm or ±2%
Display Type: Large LED or TFT screen
Waveform Display: Plethysmograph (real-time pulse waveform)
Alarm Functions: Adjustable thresholds for SpOâ‚‚ and PR, with sound and visual indicators
Power Supply:
– AC mains (100 – 240V, 50/60 Hz)
– Built-in rechargeable battery
Battery Backup: 4 – 8 hours of operation
Data Storage: Up to 72 hours or more
Connectivity: USB / RS232 / LAN
Weight: ~1.5 – 3 kg
Operating Environment:
– Temperature: 5°C – 40°C
– Humidity: ≤85% non-condensing
Light Source: LED or halogen (battery-operated or rechargeable)
Materials: Stainless steel instruments
Common Tools Included:
Otoscope with specula
Nasal speculum
Laryngeal mirror with handle
Tongue depressor
Case: Compact, foam-lined protective box
