Features:
Designed to provide a continuous flow of highly purified air over critical areas by removing airborne contaminants
Mounted directly into the ceiling structure to maximize workspace flexibility and minimize floor obstruction
Unidirectional laminar airflow creates a sterile, particle-free environment for sensitive operations
High-Efficiency Particulate Air (HEPA) or Ultra-Low Penetration Air (ULPA) filters ensure high air cleanliness levels
Stainless steel or powder-coated outer casing for corrosion resistance and easy cleaning
Integrated pre-filters extend the life of main HEPA/ULPA filters by trapping larger particles
Variable airflow velocity control to adapt to different operational needs
Low-noise and low-vibration fan systems for maintaining a quiet work environment
Energy-efficient motorized blowers ensure continuous performance with minimal power consumption
LED lighting integrated within the unit for clear visibility without disturbing airflow patterns
Can be configured with optional differential pressure gauges, alarms for filter clogging, and remote monitoring systems
Suitable for installation in modular cleanrooms, operation theaters, pharmaceutical production units, laboratories, and electronics manufacturing
| Type | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Standard Ceiling LAF | DR CMLAF SPU | Basic ceiling-mounted unit for controlled environments. | Air Velocity: 0.45 ± 0.05 m/s Filtration: HEPA 99.99%@0.3µ Material: SS304/HPL Size: 1200×1200 mm |
– Easy ceiling integration – Energy efficient – Uniform airflow – Cost-effective |
| Modular Ceiling LAF | DR CMLAF MPS | For large clean zones using modular HEPA units in combination. | ISO Class: 5 Airflow: Laminar vertical Panels: 2–10 modular Noise: <60 dB |
– Scalable design – Full ceiling coverage – Customizable layout – Easy maintenance |
| Flush Ceiling LAF | DR CMLAF IFMS | Flush with ceiling tiles for seamless cleanroom ceilings. | HEPA Filter: Mini-pleat Face Velocity: 0.3–0.5 m/s Diffuser: Perforated SS Pressure Drop: <150 Pa |
– Smooth cleanroom surface – No particle traps – Compatible with BMS – Aesthetic finish |
| OT Laminar Ceiling (AHU-connected) | DR CMLAF CAS | Ceiling LAF integrated with AHU for OTs & ICUs. | ISO Class 5 (OT) Air Changes: >90/hr Supply Plenum: SS304 AHU-Connected |
– Central air handling – Zonal temperature control – Designed for surgical asepsis – Seamless lighting & FFU integration |
| HEPA Ceiling Module | DR CMLAF SFFU | Small, standalone FFU module for spot clean zones. | HEPA: H14 or U15 FFU with EC Motor Size: 600×600 / 1200×600 mm Noise: <55 dB |
– Plug & play – Retrofit-friendly – Energy efficient – Maintenance access from below |
| Double HEPA LAF | DR CMLAF DSS | Includes pre-filter and secondary ULPA/HEPA for ultra-clean air. | ULPA: 99.9995%@0.12µ Pre-filter: G4/F7 Velocity: 0.45 m/s Material: SS316 |
– Superior particle retention – Ultra-sterile output – Used in IVF or transplant OTs – High-efficiency filtration |
| Negative Pressure LAF Ceiling | DR CMLAF IRC | Designed for infectious zones like TB wards. | Pressure: -20 to -30 Pa Exhaust: HEPA filtered Flow: Vertical down ISO Class: 7 or better |
– Prevents cross contamination – Negative pressure zones – 24/7 monitoring compatibility |
| Positive Pressure LAF Ceiling | DR CMLAF CLU | Maintains positive pressure to keep particles out. | Air Changes: 20–30/hr HEPA: H13/14 Temperature: 20–24°C Humidity: 45–55% |
– Particle exclusion – Designed for embryology – Silent operation – Seamless integration |
| LED Integrated LAF Ceiling | DR CMLAF HLAF | Combines LED surgical lighting with clean airflow. | Illumination: 1000–160,000 Lux Filter: HEPA/ULPA Noise: <60 dB Size: Custom |
– Surgical-grade lighting – Aesthetic & functional – Easy ceiling fit – Dimming and control options |
Common Customization Options:
Filter type (HEPA H13/H14 or ULPA)
Material (SS304, SS316, powder-coated GI)
Size (600×600 mm up to full ceiling grid)
Air handling integration (standalone FFU or AHU-connected)
Control system (BMS, PLC-based, manual)
| Type | Model No. | Description | Specifications | Features |
| LED X-Ray View Box (Standard) | DR-XRVS-STD | Available in single to four-film viewers; energy-efficient with film activation switch. | Brightness: 12,000–15,000 Lux; Power: AC100–240V; Brightness control: Rotary; Sizes: Single to Four Film. | Energy-efficient; Film activation switch; Wall-mountable. |
| LED X-Ray View Box (Slim Design) | DR-XRVS-SDN | Elegant slim design with aluminum body; high-quality viewing screen. | Sizes: Single to Four Film; Viewing area: 14″x17″ to 56″x17″; LED life: >100,000 hours; Power: AC110–220V. | Slim design; Uniform and soft light; Intensity regulator on panel. |
| LED X-Ray View Box (High-End) | DR-XRVS-HHD | Slim, durable, and energy-effective; suitable for MRI, CT, and X-ray images. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Quadruple Screen; LED life: 100,000 hours. | No UV emission; Magnetic nipper; 12-step digital dimmer; Automatic shutdown if no film inserted. |
| LED X-Ray View Box (Economy Version) | DR-XRVS-ENV | Slim and effective; external power adapter; suitable for budget-conscious settings. | Brightness: >6,500 Lux; Power: 15W–30W; Sizes: Single and Double Screen; LED life: 100,000 hours. | Energy-efficient; 10-step digital dimmer; External power adapter. |
| Flush Mounted LED X-Ray Viewer | DR-XRVS-FM | Designed for modular operation theatres; concealed wall installation. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Four Screen; LED life: 100,000 hours. | Seamless design; Maintains sterile environment; 6500K color temperature. |
| Dental LED X-Ray Viewer | DR-XRVS-DTL | Specifically for dental use; compact and lightweight. | Viewing area: 492×217 mm; Power: 10W; Brightness: >7,500 Lux; LED life: 100,000 hours. | Portable; Shockproof; Suitable for OPG films. |
| LED X-Ray View Box (Deluxe) | DR-XRVS-DLX | High brightness with excellent luminance uniformity; wall and table mounted. | Brightness: >10,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | Flicker-free; Inbuilt power supply; 2-year warranty; Film sensor and dimmer included. |
| LED X-Ray View Box (Premium) | DR-XRVS-PM | Slimmest design with high brightness; suitable for detailed image viewing. | Brightness: >7,500 Lux; Power: 30W–120W; Sizes: Single to Four Film; LED life: 100,000 hours. | 25mm thickness; Flicker-free; Inbuilt power supply; Film sensor and dimmer included. |
| LED X-Ray View Box (Economy) | DR-XRVS-ECN | Budget-friendly with adequate brightness; wall-mounted design. | Brightness: Up to 3,000 Lux; Power: 10W–20W; Sizes: Single and Double Film; LED life: 100,000 hours. | 70mm thickness; Flicker-free; Film sensor and dimmer included. |
| LED X-Ray View Box with Dimmer & Sensor | DR-XRVS-DMS | High-quality product with dimmer and sensor; trusted globally. | Brightness: 15,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | 45mm thickness; 7000K color temperature; Wall-mountable. |
| LED X-Ray Film View Box (Triple) | DR-XRVS-T3 | Triple film viewer with advanced features; suitable for various film types. | Brightness: 0–6,000 cd/m²; Power: 90W; Viewing area: 1080×422 mm; LED life: 100,000 hours. | PWM dimming system; LCD display; Automatic sensing function; Memory function. |
| LED X-Ray Film View Box (Single) | DR-XRVS-S1 | Single film viewer with compact design; suitable for various film types. | Brightness: 0–4,500 cd/m²; Power: 30W; Viewing area: 360×425 mm; LED life: 100,000 hours. | 25mm thickness; PWM dimming system; Automatic film activation; Eye protective feature. |
| Ultra Slim LED X-Ray View Box | DR-XRVS-UTS | Ultra-slim design with sensor and dimmer; suitable for detailed image viewing. | Brightness: 10,000 Lux; Power: 30W; Viewing area: 14″x17″; LED life: 100,000 hours. | 25mm thickness; 8000K color temperature; Wall-mountable. |
| Sl no. | Type of Wash Basin | Model | Specification | Key Features | Description |
| 1 | Wall-Mounted Ceramic Basin | DR-WB-WM | Size: ~550×400×180 mm, IR sensor tap, ceramic body | Cost-effective, easy to install, auto shut-off sensor | Ideal for public restrooms, schools, and hospitals |
| 2 | Countertop Basin with Sensor | DR-WB-CB | Basin placed on counter, sensor faucet installed separately | Aesthetic design, durable finish, easy sensor access | Used in commercial offices, hotels, premium clinics |
| 3 | Integrated Sensor Basin Unit | DR-WB-IS | All-in-one basin with built-in tap, sensor, and soap dispenser | Compact design, plug & play, minimal plumbing | Suitable for high-end healthcare or corporate facilities |
| 4 | Stainless Steel Basin | DR-WB-SS | SS304/316 grade, vandal-proof sensor faucet, industrial finish | Durable, corrosion-resistant, sensor with battery/AC options | Best for industrial kitchens, labs, railway stations |
| 5 | Double/Triple Wash Station | DR-WB-DT | Multi-user basin with 2–3 sensors and taps integrated | Space-efficient, high-throughput, anti-drip sensor system | Suitable for operation theatres, ICUs, and high-traffic zones |
| 6 | Pediatric Sensor Basin | DR-WB-PD | Lower height, colorful design, gentle water flow sensor | Child-safe design, soft edges, temperature-controlled | Ideal for pediatric hospitals, schools, and child care centers |
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Hermetically Sealed Sliding Door: Manual Single Leaf | DR H2SD MSL | Manually operated single-panel sliding door with hermetic seal for OTs and cleanrooms. | Size: 1200 x 2100 mm Leaf: Single Material: SS / HPL / Powder-coated GI Seal: Bottom + perimeter Opening: Manual push-pull |
– Smooth manual glide – Full hermetic sealing – Easy maintenance – Ideal for small OTs |
| Hermetically Sealed Sliding Door: Automatic Single-Leaf | DR H2SD ASL | Automated sliding door with sensor-based motion and full perimeter seal for infection control zones. | Drive: Microprocessor-controlled Size: 1200 x 2100 mm Opening Speed: 250–500 mm/sec Sensors: Infrared / microwave Power: 230V AC |
– Touchless operation – Hermetically sealed – Anti-crush safety – Silent motor |
| Hermetically Sealed Sliding Door: Automatic Double-Leaf | DR H2SD ADL | Wide-opening automatic dual-leaf sliding door for gurney and equipment movement. | Leaf Size: 2 x 1200 mm Total Opening: 2400 mm Material: SS304 / HPL Motor: Belt drive Sensors: Dual-zone presence sensor |
– Large clear opening – Double leaf automation – Medical-grade surface – Optional battery backup |
| Hermetically Sealed Sliding Door: Lead-Lined Radiation Proof | DR H2SD L2RF | Radiation-shielding sliding door for imaging/OT rooms with hermetic sealing. | Shielding: 2 mm Pb equivalence Leaf: SS/Lead/HPL composite Seal: 3-side hermetic Automation: Optional |
– X-ray/MRI compatible – Anti-radiation core – Smooth, quiet operation |
| Hermetically Sealed Sliding Door: Glass Panel with SS Frame | DR H2SD SPS | Transparent hermetic door with clear toughened glass for visibility between zones. | Glass: 10–12 mm toughened Frame: SS 304 Size: 1500 x 2100 mm Seal: Bottom drop seal Motor: Optional |
– Modern aesthetic – Visual access – Hermetic bottom seal – Cleanroom compliant |
| Hermetically Sealed Sliding Door: ICU/Isolation Room Bi-Parting | DR H2SD I2R2P | Bi-parting auto door system for ICU and isolation wards with negative pressure sealing. | Leaf Size: 2 x 1000 mm Motor: Low-noise linear motor Controls: Touchless switch Finish: Antibacterial HPL or SS |
– Suited for ICU/clean zones – Pressure integrity – Hands-free access |
| Hermetically Sealed Sliding Door: Fire Rated with Hermetic Seal | DR H2SD FRS | Sliding door certified for fire safety and hermetic sealing up to 60 minutes. | Fire Rating: EI60 Seal: Intumescent + hermetic Core: Rockwool + GI Automation: Available |
– Fire-resistant – Sealed for smoke/gas – Fire-rated glazing optional |
Access control (RFID, keypad, facial recognition)
Battery backup for motor
Touchless sensors and foot switches
Door status indicator lights (Red/Green)
Vision panels or X-ray safe glass
Cleanroom-rated antibacterial coatings
| Type | Model NO | Description | Specifications | Features |
|---|---|---|---|---|
| Standard IVF OT | DR ORIVF BMS | Entry-level OT for small to mid-sized IVF clinics. | Size: 200–300 sq.ft. Wall: HPL/SS Panels Floor: Antistatic vinyl HVAC: HEPA @ 0.3µ Lighting: 600 lux LED |
– Cost-effective – Laminar airflow – Integrated IVF lab support – Low maintenance |
| Advanced IVF OT | DR ORIVF EL | Includes OT and adjacent IVF laboratory. | Size: 300–500 sq.ft. Wall: SS304 with HPL cladding HVAC: ISO Class 7 Temp: 21–23°C Humidity: 45–55% |
– Seamless lab-OT operation – Pass box integration – Modular cleanroom walls – Pressure differential system |
| IVF Clean Room OT | DR ORIVF 1000CC | High-grade cleanroom OT for embryo transfer & ICSI. | ISO Class 6–7 HEPA: 99.997%@0.3µ Air changes: >25/hr Floor: Conductive ESD tiles |
– ISO-compliant air filtration – Epoxy-coated surfaces – Contamination control – Data logging systems |
| Mobile IVF OT | DR ORIVF PTU | Portable modular OT for remote or tier-2 city clinics. | Fully contained unit Power: Generator + UPS Built-in HVAC Size: ~300 sq.ft. |
– Transportable – All-in-one setup – Minimal installation – Quick deployment |
| Smart IVF OT | DR ORIVF IOT | Digitally integrated IVF OT with monitoring systems. | Real-time temp/humidity monitoring Integrated BMS Access control Surveillance |
– Remote monitoring – Live streaming of procedures – Touchless controls – IVF-specific software systems |
| Hybrid IVF OT | DR ORIVF OTPIR | Combines IVF OT with ultrasound & cryo-storage. | Imaging: Integrated USG Cooling: Cryogenic storage LED OT lights: 160,000 lux Modular partitions |
– Imaging + storage in OT – Advanced ventilation – One-way workflow – Seamless operation |
| HEPA Ceiling Modular OT | DR ORIVF LFC | Focuses on air cleanliness at the embryo work zone. | HEPA ceiling panels Vertical laminar flow FFU modules Air pressure >15 Pa |
– Max contamination control – Quiet FFU operation – Low particulate count – Ideal for embryo handling |
| Bio-safe IVF OT | DR ORIVF AMC | Prioritizes infection control & sterility. | Antimicrobial paint Flush doors UV-resistant fixtures SS304 touchpoints |
– Easy sterilization – Inbuilt biohazard control – Seamless corners – Anti-bacterial surfaces |
