| Sl no. | Type of Wash Basin | Model | Specification | Key Features | Description |
| 1 | Wall-Mounted Ceramic Basin | DR-WB-WM | Size: ~550×400×180 mm, IR sensor tap, ceramic body | Cost-effective, easy to install, auto shut-off sensor | Ideal for public restrooms, schools, and hospitals |
| 2 | Countertop Basin with Sensor | DR-WB-CB | Basin placed on counter, sensor faucet installed separately | Aesthetic design, durable finish, easy sensor access | Used in commercial offices, hotels, premium clinics |
| 3 | Integrated Sensor Basin Unit | DR-WB-IS | All-in-one basin with built-in tap, sensor, and soap dispenser | Compact design, plug & play, minimal plumbing | Suitable for high-end healthcare or corporate facilities |
| 4 | Stainless Steel Basin | DR-WB-SS | SS304/316 grade, vandal-proof sensor faucet, industrial finish | Durable, corrosion-resistant, sensor with battery/AC options | Best for industrial kitchens, labs, railway stations |
| 5 | Double/Triple Wash Station | DR-WB-DT | Multi-user basin with 2–3 sensors and taps integrated | Space-efficient, high-throughput, anti-drip sensor system | Suitable for operation theatres, ICUs, and high-traffic zones |
| 6 | Pediatric Sensor Basin | DR-WB-PD | Lower height, colorful design, gentle water flow sensor | Child-safe design, soft edges, temperature-controlled | Ideal for pediatric hospitals, schools, and child care centers |
| Type | Model | Description | Specifications | Features |
| Wall-Mounted | DR H3SÂ SS 1 | Single-user stainless steel scrub station | 304 SS, 36″ wide, hands-free sensor | IR sensor tap, knee-operated soap, backsplash panel |
| Double Basin | DR H3SÂ DS 2 | Two-person scrub station | Dual 24″ basins, 16-gauge SS | Timer faucet, antimicrobial coating, soap dispensers |
| Triple Basin | DR H3SÂ TS 3 | Multi-user high-traffic scrub sink | 72″ long, three compartments, wall mounted | Infrared faucet, auto-temp control, elbow soap |
| Mobile Unit | DR H3SÂ MU 1 | Portable scrub station for temporary setups | Compact, wheels with locks, 20L water tanks | Foot pump, removable tanks, integrated storage |
| Compact Corner | DR H3SÂ CC 1 | Space-saving corner scrub sink | Triangular SS build, 30″ sides | Elbow-operated faucet, splash guard, compact form |
| Recessed Model | DR H3SÂ RM 1 | Flush-mounted unit for minimal intrusion | Built-in wall unit, SS front panel | Infrared faucet, soap niche, sleek design |
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Storage Cupboard: SS Double Door Instrument Cabinet | DR CBTR SC2D | Stainless steel cabinet for storing sterile instruments and packs in OTs or sterile areas. | Material: SS 304 Size: 1800(H) x 900(W) x 450(D) mm Doors: Glass/SS Shelves: 4 adjustable |
– Rust-proof – Lockable doors – Easy to clean – Hospital-grade finish |
| Storage Cupboard: Powder-Coated MS Medicine Cabinet | DR CBTR SCPC | Mild steel cupboard for general ward and pharmacy storage. | Material: MS with epoxy coating Size: 1200 x 900 x 400 mm Lock: Individual key Shelves: 3–4 |
– Budget-friendly – Durable – Scratch resistant – Wall or floor mount |
| Storage Cupboard: Wall-Mounted SS Overhead Unit | DR CBTR SCWM | Compact overhead cupboard for ICU or recovery units. | Size: 600 x 450 x 300 mm Material: SS 304 Mount: Wall-mounted Doors: Sliding |
– Space-saving – Ideal for consumables – Seamless corners |
| Instrument Trolley: 2 Shelves with Guard Rails | DR CBTR IT2S | Mobile trolley for surgical instruments in OTs. | Size: 900 x 600 x 900 mm Material: SS 304 Castors: 100 mm dia (2 brakes) Shelves: 2 with railing |
– Easy maneuverability – Rust-proof – Smooth surface – High load capacity |
| Instrument Trolley: 3 Shelves with Drawer | DR CBTR IT3S | Multi-level SS trolley with added storage drawer. | Size: 1000 x 600 x 950 mm Shelves: 3 Drawer: SS pull-type Castors: Swivel 4″ |
– Added storage – Non-marking wheels – Robust design |
| Dressing Trolley: SS with Bowl & Bucket | DR CBTR DT2S | Used for patient dressing procedures in wards and emergency rooms. | Size: 900 x 500 x 900 mm Accessories: 1 SS bowl, 1 bucket Shelves: 2 Rails: 3 sides |
– Complete set – Easy to sanitize – Locking wheels |
| Crash Cart Trolley: 5 Drawer with IV Pole | DR CBTR CT5D | Emergency response trolley for ICU and ER setups. | Material: MS powder coated Drawers: 5 + CPR board IV Pole: Adjustable Wheels: 125 mm, 2 with brakes |
– Designed for emergencies – Multi-drawer – Defibrillator shelf |
| Linen Trolley: Foldable with Canvas Bag | DR CBTR LTCB | Trolley for soiled linen collection in wards. | Frame: SS 304 Bag: Detachable canvas Wheels: 4″ non-marking Foldable: Yes |
– Space saving – Washable bag – Sturdy frame |
| Medicine Trolley: Lockable with Removable Trays | DR CBTR MTLRT | Medication distribution trolley for nursing stations. | Material: MS powder-coated Trays: 12–16 removable Lock: Central Wheels: 4 with brakes |
– Secure medication handling – Custom tray layout – Durable construction |
| Oxygen Cylinder Trolley: Single with Handle | DR CBTR OCTS | Trolley to transport single oxygen cylinder safely. | Capacity: 1 cylinder (B/D type) Frame: SS 304 Wheels: 6″ rubber Handle: Ergonomic |
– Safe transport – Stable base – Corrosion resistant |
Common Materials:
Stainless Steel (SS 304) – corrosion-resistant, sterile zones
Mild Steel (MS) with Powder Coating – cost-effective for non-sterile areas
Medical-grade Castors – smooth movement, anti-static options available
| Type (with Configuration) | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Central Oxygen Supply System: Manifold + Bulk Tank | DR HGPS COSS | Supplies medical-grade oxygen to all zones from LOX tank or high-pressure cylinders. | Pressure: 4.2–5.0 bar Source: LOX/D-type Cylinders Pipeline: Degreased Copper (EN 13348) Alarm: Digital panel |
– Auto changeover manifold – Fire-safe ball valves – Pressure relief system – Audible/visual alarms |
| Medical Air System: Duplex Oil-Free Compressor + Air Dryer + Receiver | DR HGPS MAS | Delivers clean compressed air for respiratory use and surgical tools. | Output: 4.5–5.5 bar Compressor: 100% Oil-Free Scroll Receiver: 500 Ltr Dew Point: -40°C |
– Redundant operation – Bacteria filter & dryer – Noise-insulated cabinet – Pressure sensors |
| Vacuum System: Central Suction Pump + Receiver + Filter | DR HGPS VS | Provides centralized suction for OT, ICU, and critical care units. | Vacuum: -600 to -650 mmHg Pumps: 2x Rotary Vane (3 HP each) Receiver: 300 Ltr Filtration: Bacterial trap |
– Automatic pump alternation – Non-lubricated design – Overflow & noise control |
| Nitrous Oxide Supply: Manifold Cylinder Bank System | DR HGPS N2OS | Used in anesthesia delivery systems across OTs. | Pressure: 4.5–5.0 bar Cylinders: 12 Bank Piping: Degreased copper Alarm: Low pressure |
– Automatic switching – Safety relief valve – Medical color-coding (blue) |
| Medical Gas Alarm System: Area + Master Panels | DR HGPS MGAS | Monitors pressure levels and triggers alerts in all gas zones. | Zones: 7 Display: LED Digital Power: 230V AC Mounting: Wall surface/recessed |
– Audible & visual alert – Optional BMS integration – Real-time pressure monitoring |
| Bed Head Panel: Horizontal 3-Gas + Nurse Call + Power | DR HGPS BHP | Multi-utility horizontal panel for patient headwalls. | Length: 1200 mm Outlets: O2, Air, Vacuum Electrical: 3 sockets + nurse call Material: Aluminum |
– Modular, low maintenance – Gas & power segregation – LED night light (optional) |
| OT Pendant System: Double Arm with Gas, Electrical & Shelves | DR HGPS OTPS | Ceiling-mounted system for OT with movable arms and console. | Arm Length: 600+600 mm Gas Outlets: 6–8 types Load: Up to 200kg Rotation: 330° |
– 2-arm design for flexibility – Integrated gas & power – ICU & surgical variants |
| Anesthesia Gas Scavenging System: Active Type | DR HGPS AG2S | Extracts waste anesthetic gases to protect medical staff. | Flow Rate: 100–150 L/min Pressure: -20 to -40 mbar Filters: Inline HEPA Compliance: HTM 2022 |
– Staff exposure reduction – Low noise – Central or local exhaust options |
| Zone Valve Box: 5 Line with Monitoring Window | DR HGPS ZVB5 | Isolates gas lines for specific zones during servicing or emergency. | Lines: 5 Valve Type: ¼-turn brass Box: Powder-coated steel Labeling: Laser-etched |
– Transparent window – Lockable design – Color-coded tubing |
| Copper Medical Gas Piping Network: Degreased, EN Certified | DR HGPS CUMSPN | Backbone piping system for MGPS distribution across hospital floors. | Size: 10 mm to 54 mm Material: Copper EN 13348 Joint: Silver brazed Test Pressure: 1.5x Working Pressure |
– Smooth internal bore – Corrosion-resistant – Suitable for oxygen & vacuum |
