| Type | Model No. | Description | Specifications | Features |
| LED X-Ray View Box (Standard) | DR-XRVS-STD | Available in single to four-film viewers; energy-efficient with film activation switch. | Brightness: 12,000–15,000 Lux; Power: AC100–240V; Brightness control: Rotary; Sizes: Single to Four Film. | Energy-efficient; Film activation switch; Wall-mountable. |
| LED X-Ray View Box (Slim Design) | DR-XRVS-SDN | Elegant slim design with aluminum body; high-quality viewing screen. | Sizes: Single to Four Film; Viewing area: 14″x17″ to 56″x17″; LED life: >100,000 hours; Power: AC110–220V. | Slim design; Uniform and soft light; Intensity regulator on panel. |
| LED X-Ray View Box (High-End) | DR-XRVS-HHD | Slim, durable, and energy-effective; suitable for MRI, CT, and X-ray images. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Quadruple Screen; LED life: 100,000 hours. | No UV emission; Magnetic nipper; 12-step digital dimmer; Automatic shutdown if no film inserted. |
| LED X-Ray View Box (Economy Version) | DR-XRVS-ENV | Slim and effective; external power adapter; suitable for budget-conscious settings. | Brightness: >6,500 Lux; Power: 15W–30W; Sizes: Single and Double Screen; LED life: 100,000 hours. | Energy-efficient; 10-step digital dimmer; External power adapter. |
| Flush Mounted LED X-Ray Viewer | DR-XRVS-FM | Designed for modular operation theatres; concealed wall installation. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Four Screen; LED life: 100,000 hours. | Seamless design; Maintains sterile environment; 6500K color temperature. |
| Dental LED X-Ray Viewer | DR-XRVS-DTL | Specifically for dental use; compact and lightweight. | Viewing area: 492×217 mm; Power: 10W; Brightness: >7,500 Lux; LED life: 100,000 hours. | Portable; Shockproof; Suitable for OPG films. |
| LED X-Ray View Box (Deluxe) | DR-XRVS-DLX | High brightness with excellent luminance uniformity; wall and table mounted. | Brightness: >10,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | Flicker-free; Inbuilt power supply; 2-year warranty; Film sensor and dimmer included. |
| LED X-Ray View Box (Premium) | DR-XRVS-PM | Slimmest design with high brightness; suitable for detailed image viewing. | Brightness: >7,500 Lux; Power: 30W–120W; Sizes: Single to Four Film; LED life: 100,000 hours. | 25mm thickness; Flicker-free; Inbuilt power supply; Film sensor and dimmer included. |
| LED X-Ray View Box (Economy) | DR-XRVS-ECN | Budget-friendly with adequate brightness; wall-mounted design. | Brightness: Up to 3,000 Lux; Power: 10W–20W; Sizes: Single and Double Film; LED life: 100,000 hours. | 70mm thickness; Flicker-free; Film sensor and dimmer included. |
| LED X-Ray View Box with Dimmer & Sensor | DR-XRVS-DMS | High-quality product with dimmer and sensor; trusted globally. | Brightness: 15,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | 45mm thickness; 7000K color temperature; Wall-mountable. |
| LED X-Ray Film View Box (Triple) | DR-XRVS-T3 | Triple film viewer with advanced features; suitable for various film types. | Brightness: 0–6,000 cd/m²; Power: 90W; Viewing area: 1080×422 mm; LED life: 100,000 hours. | PWM dimming system; LCD display; Automatic sensing function; Memory function. |
| LED X-Ray Film View Box (Single) | DR-XRVS-S1 | Single film viewer with compact design; suitable for various film types. | Brightness: 0–4,500 cd/m²; Power: 30W; Viewing area: 360×425 mm; LED life: 100,000 hours. | 25mm thickness; PWM dimming system; Automatic film activation; Eye protective feature. |
| Ultra Slim LED X-Ray View Box | DR-XRVS-UTS | Ultra-slim design with sensor and dimmer; suitable for detailed image viewing. | Brightness: 10,000 Lux; Power: 30W; Viewing area: 14″x17″; LED life: 100,000 hours. | 25mm thickness; 8000K color temperature; Wall-mountable. |
| Sl no. | Type of Wash Basin | Model | Specification | Key Features | Description |
| 1 | Wall-Mounted Ceramic Basin | DR-WB-WM | Size: ~550×400×180 mm, IR sensor tap, ceramic body | Cost-effective, easy to install, auto shut-off sensor | Ideal for public restrooms, schools, and hospitals |
| 2 | Countertop Basin with Sensor | DR-WB-CB | Basin placed on counter, sensor faucet installed separately | Aesthetic design, durable finish, easy sensor access | Used in commercial offices, hotels, premium clinics |
| 3 | Integrated Sensor Basin Unit | DR-WB-IS | All-in-one basin with built-in tap, sensor, and soap dispenser | Compact design, plug & play, minimal plumbing | Suitable for high-end healthcare or corporate facilities |
| 4 | Stainless Steel Basin | DR-WB-SS | SS304/316 grade, vandal-proof sensor faucet, industrial finish | Durable, corrosion-resistant, sensor with battery/AC options | Best for industrial kitchens, labs, railway stations |
| 5 | Double/Triple Wash Station | DR-WB-DT | Multi-user basin with 2–3 sensors and taps integrated | Space-efficient, high-throughput, anti-drip sensor system | Suitable for operation theatres, ICUs, and high-traffic zones |
| 6 | Pediatric Sensor Basin | DR-WB-PD | Lower height, colorful design, gentle water flow sensor | Child-safe design, soft edges, temperature-controlled | Ideal for pediatric hospitals, schools, and child care centers |
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Operation Theatre Control Panel: Touchscreen PLC-Based | DR OTCP TSPLC | Digital control panel with 7” touchscreen and PLC for complete OT environment management. | Display: 7″ HMI Touch Control: PLC-based Power: 230V AC Interface: Modbus/BMS Mount: Flush wall-mounted |
– Centralized control – User-friendly interface – Programmable alerts – Password protection |
| Operation Theatre Control Panel: Membrane Type with Push Buttons | DR OTCP MB6F | Conventional push-button-based panel for managing 6 OT functions. | Functions: 6 (light, fan, temp, etc.) Material: SS304 front plate Indicators: LED Voltage: 230V AC |
– Cost-effective – Reliable and durable – Simple operation |
| Operation Theatre Control Panel: Hybrid Touch + Membrane | DR OTCP HTM | Combines membrane switches with a digital display for basic automation. | Display: Digital segment Switches: Membrane + tactile Enclosure: SS or powder-coated MS Size: 400×300 mm |
– Combines digital + manual – Semi-automated – Backlit buttons |
| Operation Theatre Control Panel: Glass Front Touchscreen | DR OTCP GFTS | Full glass front panel for high-end modular OTs with 10” touchscreen. | Display: 10” capacitive touch Material: Tempered glass Power: 230V Mounting: Recessed wall panel |
– Sleek design – Anti-bacterial surface – BMS compatible |
| Operation Theatre Control Panel: Nurse Station Interface Panel | DR OTCP NSIP | Wall-mounted panel allowing communication and control for nurses inside OT. | Functions: Intercom, Music, Timer, Lights Display: LED/Touchscreen Mount: Surface/flush Comms: Wired/wireless |
– Nurse call + communication – Music and clock integrated – Quick access panel |
| Operation Theatre Control Panel: HVAC & Light Integration Panel | DR OTCP HLI | Dedicated control unit for lighting and air handling unit inside OT. | Lighting: Dimming control HVAC: Temp display + setpoint Relay: 230V Display: Digital/Touch |
– HVAC & lighting in one unit – Alarm integration – SS housing |
| Operation Theatre Control Panel: Alarm & Timer Focused Unit | DR OTCP ATF | Compact unit focusing on elapsed time, clock, and critical OT alerts. | Timers: Elapsed, anesthesia Clock: 24hr format Alarms: OT door, gas Display: 3.5” digital LED |
– Ideal for retrofit – Easy wall installation – Low maintenance |
Digital Clock (24 hr)
Elapsed Time Indicator
Temperature & Humidity Display
HEPA Filter Status Alarm
Medical Gas Pressure Alarms
Lighting & Fan Control
Music System
Nurse Call / Intercom
Material: SS304, powder-coated CRCA, or toughened glass front
Mounting: Flush/recessed or wall-mounted
Interfaces: RS485, Modbus, BMS-ready, SCADA-compatible
