Features:
Centralized control unit for managing all critical functions in a modular operation theatre
Flush-mounted design with smooth surface to maintain hygiene and sterility
User-friendly interface with tactile buttons or touchscreen for ease of operation
Customizable layout based on hospital or project requirements
Controls essential functions including medical gas alarm system, lighting, temperature, humidity, and clock systems
Digital display of parameters like room temperature, humidity level, time, and pressure
Integrated stopwatch and elapsed time indicator for surgical timing
Interlocking controls for electrical circuits, surgical lights, and ventilation systems
Audible and visual alarms for fault detection and system warnings
Microprocessor or PLC-based logic control for accuracy and reliability
Easy maintenance with modular, serviceable components
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Operation Theatre Control Panel: Touchscreen PLC-Based | DR OTCP TSPLC | Digital control panel with 7” touchscreen and PLC for complete OT environment management. | Display: 7″ HMI Touch Control: PLC-based Power: 230V AC Interface: Modbus/BMS Mount: Flush wall-mounted |
– Centralized control – User-friendly interface – Programmable alerts – Password protection |
| Operation Theatre Control Panel: Membrane Type with Push Buttons | DR OTCP MB6F | Conventional push-button-based panel for managing 6 OT functions. | Functions: 6 (light, fan, temp, etc.) Material: SS304 front plate Indicators: LED Voltage: 230V AC |
– Cost-effective – Reliable and durable – Simple operation |
| Operation Theatre Control Panel: Hybrid Touch + Membrane | DR OTCP HTM | Combines membrane switches with a digital display for basic automation. | Display: Digital segment Switches: Membrane + tactile Enclosure: SS or powder-coated MS Size: 400×300 mm |
– Combines digital + manual – Semi-automated – Backlit buttons |
| Operation Theatre Control Panel: Glass Front Touchscreen | DR OTCP GFTS | Full glass front panel for high-end modular OTs with 10” touchscreen. | Display: 10” capacitive touch Material: Tempered glass Power: 230V Mounting: Recessed wall panel |
– Sleek design – Anti-bacterial surface – BMS compatible |
| Operation Theatre Control Panel: Nurse Station Interface Panel | DR OTCP NSIP | Wall-mounted panel allowing communication and control for nurses inside OT. | Functions: Intercom, Music, Timer, Lights Display: LED/Touchscreen Mount: Surface/flush Comms: Wired/wireless |
– Nurse call + communication – Music and clock integrated – Quick access panel |
| Operation Theatre Control Panel: HVAC & Light Integration Panel | DR OTCP HLI | Dedicated control unit for lighting and air handling unit inside OT. | Lighting: Dimming control HVAC: Temp display + setpoint Relay: 230V Display: Digital/Touch |
– HVAC & lighting in one unit – Alarm integration – SS housing |
| Operation Theatre Control Panel: Alarm & Timer Focused Unit | DR OTCP ATF | Compact unit focusing on elapsed time, clock, and critical OT alerts. | Timers: Elapsed, anesthesia Clock: 24hr format Alarms: OT door, gas Display: 3.5” digital LED |
– Ideal for retrofit – Easy wall installation – Low maintenance |
Digital Clock (24 hr)
Elapsed Time Indicator
Temperature & Humidity Display
HEPA Filter Status Alarm
Medical Gas Pressure Alarms
Lighting & Fan Control
Music System
Nurse Call / Intercom
Material: SS304, powder-coated CRCA, or toughened glass front
Mounting: Flush/recessed or wall-mounted
Interfaces: RS485, Modbus, BMS-ready, SCADA-compatible
| Type | Model | Description | Specifications | Features |
| Wall-Mounted | DR H3S SS 1 | Single-user stainless steel scrub station | 304 SS, 36″ wide, hands-free sensor | IR sensor tap, knee-operated soap, backsplash panel |
| Double Basin | DR H3S DS 2 | Two-person scrub station | Dual 24″ basins, 16-gauge SS | Timer faucet, antimicrobial coating, soap dispensers |
| Triple Basin | DR H3S TS 3 | Multi-user high-traffic scrub sink | 72″ long, three compartments, wall mounted | Infrared faucet, auto-temp control, elbow soap |
| Mobile Unit | DR H3S MU 1 | Portable scrub station for temporary setups | Compact, wheels with locks, 20L water tanks | Foot pump, removable tanks, integrated storage |
| Compact Corner | DR H3S CC 1 | Space-saving corner scrub sink | Triangular SS build, 30″ sides | Elbow-operated faucet, splash guard, compact form |
| Recessed Model | DR H3S RM 1 | Flush-mounted unit for minimal intrusion | Built-in wall unit, SS front panel | Infrared faucet, soap niche, sleek design |
| Type (with Configuration) | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Central Oxygen Supply System: Manifold + Bulk Tank | DR HGPS COSS | Supplies medical-grade oxygen to all zones from LOX tank or high-pressure cylinders. | Pressure: 4.2–5.0 bar Source: LOX/D-type Cylinders Pipeline: Degreased Copper (EN 13348) Alarm: Digital panel |
– Auto changeover manifold – Fire-safe ball valves – Pressure relief system – Audible/visual alarms |
| Medical Air System: Duplex Oil-Free Compressor + Air Dryer + Receiver | DR HGPS MAS | Delivers clean compressed air for respiratory use and surgical tools. | Output: 4.5–5.5 bar Compressor: 100% Oil-Free Scroll Receiver: 500 Ltr Dew Point: -40°C |
– Redundant operation – Bacteria filter & dryer – Noise-insulated cabinet – Pressure sensors |
| Vacuum System: Central Suction Pump + Receiver + Filter | DR HGPS VS | Provides centralized suction for OT, ICU, and critical care units. | Vacuum: -600 to -650 mmHg Pumps: 2x Rotary Vane (3 HP each) Receiver: 300 Ltr Filtration: Bacterial trap |
– Automatic pump alternation – Non-lubricated design – Overflow & noise control |
| Nitrous Oxide Supply: Manifold Cylinder Bank System | DR HGPS N2OS | Used in anesthesia delivery systems across OTs. | Pressure: 4.5–5.0 bar Cylinders: 12 Bank Piping: Degreased copper Alarm: Low pressure |
– Automatic switching – Safety relief valve – Medical color-coding (blue) |
| Medical Gas Alarm System: Area + Master Panels | DR HGPS MGAS | Monitors pressure levels and triggers alerts in all gas zones. | Zones: 7 Display: LED Digital Power: 230V AC Mounting: Wall surface/recessed |
– Audible & visual alert – Optional BMS integration – Real-time pressure monitoring |
| Bed Head Panel: Horizontal 3-Gas + Nurse Call + Power | DR HGPS BHP | Multi-utility horizontal panel for patient headwalls. | Length: 1200 mm Outlets: O2, Air, Vacuum Electrical: 3 sockets + nurse call Material: Aluminum |
– Modular, low maintenance – Gas & power segregation – LED night light (optional) |
| OT Pendant System: Double Arm with Gas, Electrical & Shelves | DR HGPS OTPS | Ceiling-mounted system for OT with movable arms and console. | Arm Length: 600+600 mm Gas Outlets: 6–8 types Load: Up to 200kg Rotation: 330° |
– 2-arm design for flexibility – Integrated gas & power – ICU & surgical variants |
| Anesthesia Gas Scavenging System: Active Type | DR HGPS AG2S | Extracts waste anesthetic gases to protect medical staff. | Flow Rate: 100–150 L/min Pressure: -20 to -40 mbar Filters: Inline HEPA Compliance: HTM 2022 |
– Staff exposure reduction – Low noise – Central or local exhaust options |
| Zone Valve Box: 5 Line with Monitoring Window | DR HGPS ZVB5 | Isolates gas lines for specific zones during servicing or emergency. | Lines: 5 Valve Type: ¼-turn brass Box: Powder-coated steel Labeling: Laser-etched |
– Transparent window – Lockable design – Color-coded tubing |
| Copper Medical Gas Piping Network: Degreased, EN Certified | DR HGPS CUMSPN | Backbone piping system for MGPS distribution across hospital floors. | Size: 10 mm to 54 mm Material: Copper EN 13348 Joint: Silver brazed Test Pressure: 1.5x Working Pressure |
– Smooth internal bore – Corrosion-resistant – Suitable for oxygen & vacuum |
