Features:
Designed to provide surgeons and medical staff with a hygienic and efficient hand-washing environment before procedures
Constructed using high-grade stainless steel for durability, corrosion resistance, and easy cleaning
Seamless, rounded basin designs to minimize contamination points and ensure complete drainage
Equipped with infrared sensor-based or knee/elbow-operated water controls for touchless operation
Integrated soap dispensers, elbow-operated or sensor-controlled for infection control
Provision for hands-free water temperature adjustment to ensure user comfort and reduce contamination risk
Splash-proof, ergonomic design to prevent water spillage and ensure user convenience
Built-in thermostatic mixing valves to deliver consistent water temperature and prevent scalding
LED-illuminated scrub time indicators available in some models for timed scrubbing cycles
Back panel splash guards to protect the surrounding walls and maintain hygiene
Designed for single, double, or triple user configurations based on operation theatre requirements
Optional inclusion of knee-operated or sensor-activated hand dryers or paper towel dispensers
| Type | Model | Description | Specifications | Features |
| Wall-Mounted | DR H3SÂ SS 1 | Single-user stainless steel scrub station | 304 SS, 36″ wide, hands-free sensor | IR sensor tap, knee-operated soap, backsplash panel |
| Double Basin | DR H3SÂ DS 2 | Two-person scrub station | Dual 24″ basins, 16-gauge SS | Timer faucet, antimicrobial coating, soap dispensers |
| Triple Basin | DR H3SÂ TS 3 | Multi-user high-traffic scrub sink | 72″ long, three compartments, wall mounted | Infrared faucet, auto-temp control, elbow soap |
| Mobile Unit | DR H3SÂ MU 1 | Portable scrub station for temporary setups | Compact, wheels with locks, 20L water tanks | Foot pump, removable tanks, integrated storage |
| Compact Corner | DR H3SÂ CC 1 | Space-saving corner scrub sink | Triangular SS build, 30″ sides | Elbow-operated faucet, splash guard, compact form |
| Recessed Model | DR H3SÂ RM 1 | Flush-mounted unit for minimal intrusion | Built-in wall unit, SS front panel | Infrared faucet, soap niche, sleek design |
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Hermetically Sealed Sliding Door: Manual Single Leaf | DR H2SD MSL | Manually operated single-panel sliding door with hermetic seal for OTs and cleanrooms. | Size: 1200 x 2100 mm Leaf: Single Material: SS / HPL / Powder-coated GI Seal: Bottom + perimeter Opening: Manual push-pull |
– Smooth manual glide – Full hermetic sealing – Easy maintenance – Ideal for small OTs |
| Hermetically Sealed Sliding Door: Automatic Single-Leaf | DR H2SD ASL | Automated sliding door with sensor-based motion and full perimeter seal for infection control zones. | Drive: Microprocessor-controlled Size: 1200 x 2100 mm Opening Speed: 250–500 mm/sec Sensors: Infrared / microwave Power: 230V AC |
– Touchless operation – Hermetically sealed – Anti-crush safety – Silent motor |
| Hermetically Sealed Sliding Door: Automatic Double-Leaf | DR H2SD ADL | Wide-opening automatic dual-leaf sliding door for gurney and equipment movement. | Leaf Size: 2 x 1200 mm Total Opening: 2400 mm Material: SS304 / HPL Motor: Belt drive Sensors: Dual-zone presence sensor |
– Large clear opening – Double leaf automation – Medical-grade surface – Optional battery backup |
| Hermetically Sealed Sliding Door: Lead-Lined Radiation Proof | DR H2SD L2RF | Radiation-shielding sliding door for imaging/OT rooms with hermetic sealing. | Shielding: 2 mm Pb equivalence Leaf: SS/Lead/HPL composite Seal: 3-side hermetic Automation: Optional |
– X-ray/MRI compatible – Anti-radiation core – Smooth, quiet operation |
| Hermetically Sealed Sliding Door: Glass Panel with SS Frame | DR H2SD SPS | Transparent hermetic door with clear toughened glass for visibility between zones. | Glass: 10–12 mm toughened Frame: SS 304 Size: 1500 x 2100 mm Seal: Bottom drop seal Motor: Optional |
– Modern aesthetic – Visual access – Hermetic bottom seal – Cleanroom compliant |
| Hermetically Sealed Sliding Door: ICU/Isolation Room Bi-Parting | DR H2SD I2R2P | Bi-parting auto door system for ICU and isolation wards with negative pressure sealing. | Leaf Size: 2 x 1000 mm Motor: Low-noise linear motor Controls: Touchless switch Finish: Antibacterial HPL or SS |
– Suited for ICU/clean zones – Pressure integrity – Hands-free access |
| Hermetically Sealed Sliding Door: Fire Rated with Hermetic Seal | DR H2SD FRS | Sliding door certified for fire safety and hermetic sealing up to 60 minutes. | Fire Rating: EI60 Seal: Intumescent + hermetic Core: Rockwool + GI Automation: Available |
– Fire-resistant – Sealed for smoke/gas – Fire-rated glazing optional |
Access control (RFID, keypad, facial recognition)
Battery backup for motor
Touchless sensors and foot switches
Door status indicator lights (Red/Green)
Vision panels or X-ray safe glass
Cleanroom-rated antibacterial coatings
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Storage Cupboard: SS Double Door Instrument Cabinet | DR CBTR SC2D | Stainless steel cabinet for storing sterile instruments and packs in OTs or sterile areas. | Material: SS 304 Size: 1800(H) x 900(W) x 450(D) mm Doors: Glass/SS Shelves: 4 adjustable |
– Rust-proof – Lockable doors – Easy to clean – Hospital-grade finish |
| Storage Cupboard: Powder-Coated MS Medicine Cabinet | DR CBTR SCPC | Mild steel cupboard for general ward and pharmacy storage. | Material: MS with epoxy coating Size: 1200 x 900 x 400 mm Lock: Individual key Shelves: 3–4 |
– Budget-friendly – Durable – Scratch resistant – Wall or floor mount |
| Storage Cupboard: Wall-Mounted SS Overhead Unit | DR CBTR SCWM | Compact overhead cupboard for ICU or recovery units. | Size: 600 x 450 x 300 mm Material: SS 304 Mount: Wall-mounted Doors: Sliding |
– Space-saving – Ideal for consumables – Seamless corners |
| Instrument Trolley: 2 Shelves with Guard Rails | DR CBTR IT2S | Mobile trolley for surgical instruments in OTs. | Size: 900 x 600 x 900 mm Material: SS 304 Castors: 100 mm dia (2 brakes) Shelves: 2 with railing |
– Easy maneuverability – Rust-proof – Smooth surface – High load capacity |
| Instrument Trolley: 3 Shelves with Drawer | DR CBTR IT3S | Multi-level SS trolley with added storage drawer. | Size: 1000 x 600 x 950 mm Shelves: 3 Drawer: SS pull-type Castors: Swivel 4″ |
– Added storage – Non-marking wheels – Robust design |
| Dressing Trolley: SS with Bowl & Bucket | DR CBTR DT2S | Used for patient dressing procedures in wards and emergency rooms. | Size: 900 x 500 x 900 mm Accessories: 1 SS bowl, 1 bucket Shelves: 2 Rails: 3 sides |
– Complete set – Easy to sanitize – Locking wheels |
| Crash Cart Trolley: 5 Drawer with IV Pole | DR CBTR CT5D | Emergency response trolley for ICU and ER setups. | Material: MS powder coated Drawers: 5 + CPR board IV Pole: Adjustable Wheels: 125 mm, 2 with brakes |
– Designed for emergencies – Multi-drawer – Defibrillator shelf |
| Linen Trolley: Foldable with Canvas Bag | DR CBTR LTCB | Trolley for soiled linen collection in wards. | Frame: SS 304 Bag: Detachable canvas Wheels: 4″ non-marking Foldable: Yes |
– Space saving – Washable bag – Sturdy frame |
| Medicine Trolley: Lockable with Removable Trays | DR CBTR MTLRT | Medication distribution trolley for nursing stations. | Material: MS powder-coated Trays: 12–16 removable Lock: Central Wheels: 4 with brakes |
– Secure medication handling – Custom tray layout – Durable construction |
| Oxygen Cylinder Trolley: Single with Handle | DR CBTR OCTS | Trolley to transport single oxygen cylinder safely. | Capacity: 1 cylinder (B/D type) Frame: SS 304 Wheels: 6″ rubber Handle: Ergonomic |
– Safe transport – Stable base – Corrosion resistant |
Common Materials:
Stainless Steel (SS 304) – corrosion-resistant, sterile zones
Mild Steel (MS) with Powder Coating – cost-effective for non-sterile areas
Medical-grade Castors – smooth movement, anti-static options available
