Intuitive interface designed for quick learning and ease of use in clinical environments
Compact and portable design suitable for use in clinics, hospitals, or bedside monitoring
Streamlined workflow reduces setup time and minimizes operator errors
Enables efficient patient data handling through barcode scanning and shortcut keys
Supports seamless integration with hospital systems to enable real-time data sharing
Offers advanced diagnostic support with auto-analysis and interpretation tools
Enhances clinical decision-making with high-accuracy waveform capture and real-time review
Reliable operation with robust anti-noise and signal enhancement technologies
Facilitates collaboration among healthcare professionals through networked access
Ideal for routine exams, emergency cases, and chronic patient monitoring
Designed for long-term usability with scalable storage and software upgrade options
Optional accessories and configurations available to suit various medical facility needs
Budget-friendly options ensure accessibility without compromising on core functionality
Specifications
12-channel electrocardiograph system
8-inch high-resolution color touchscreen display
Alphanumeric keyboard for data input
Internal memory capacity for storing up to 800 ECG records
USB flash drive support for storage expansion and data export
Built-in thermal printer supporting standard thermal and A4 fax paper
USB connectivity for external printer support
Data communication via LAN and optional internal Wi-Fi
Export formats supported: PDF, SCP, FDA-XML, DICOM
Supports standard communication protocols: DICOM Worklist, HL7, GDT
24-bit analog-to-digital conversion for precise signal detection
Common-mode rejection ratio (CMRR) greater than 140dB
Real-time ECG waveform freezing and review up to 120 seconds
Automatic measurement and interpretation validated with CSE, AHA, and MIT databases
Built-in Glasgow interpretation algorithm
Optional vector ECG analysis feature
Compatible with optional SE-1515 data management software and Smart ECG Viewer
Rolling stand or trolley configuration available
Basic model variant offered for simplified applications
| Category | DR-B2 |
|---|---|
| External Size (W*D*H) | 1383*775*2250 mm |
| Internal Size (W*D*H) | 1210*600*660 mm |
| Tested Opening | Safety height 10″ |
| Max Opening | 470 mm |
| Airflow Volume (Exhaust) | 100%: 1320 m³/h (776 cfm) |
| Front Window | Motorized;Two-layer laminated toughened glass ≤6mm, Anti-UV |
| Filter | ULPA,99.9995% efficiency at 0.12μm (02), filter life indicator |
| Filter Guard Type | Aluminum alloy frame |
| Noise | NSF 49 ≤60 dB |
| Illumination | ≥1000 Lux |
| Socket | 2, Total consumption ≤500W |
| Display | Touch screen |
| Tap | Water tap*1, Gas tap*1 |
| Power Supply | AC220V,50/ 60Hz |
| Consumption | 400W |
| Alarm | Abnormal airflow velocity; Filter replacement; Front window at unsafe height |
| Blower | One ECM motor, 230V AC; Speed adjustable, high efficiency and low power consumption |
| Material | Working area: 304 stainless steel Frame,Decorative Plate: cold-rolled steel with anti- bacteria powder coating |
| UV Lamp | 30W |
| Germicidal UV Lamp | Emission of 253.7 nanometers for most efficient decontamination |
| Certification | NSF 49 |
| Illuminating Lamp | LED lamp, 20W*2 |
| Standard Accessory | LED lamp*2, UV lamp*2, Base stand, SS water tap*1, Gas tap*1, Drain valve, Waterproof socket*2 |
| Optional Accessory | Armrest, Airflow tester, Formalin fumigation sterilizer, Infrared sterilizer, exhaust duct |
| Package Size (W*D*H) | 1540*1080*1900 mm |
| Gross Weight | 340 kg |
| Temperature range | 5°C to 60°C |
| Temperature controller | Digital PID controller |
| Temperature accuracy | ±1% |
| Temperature sensor | PT-100 |
| Humidity range | 50% to 90% RH |
| Humidity controller | Digital PID controller |
| Humidity accuracy | ±3% |
| Light | 150-170 micromole/m2/sec |
| Light timer | 24×7 weekly digital timer |
| Construction | Double walled |
| Exterior | Mild steel powder coated |
| Interior | Stainless steel 304 |
| Outer door | Single or double solid doors with lock & key |
| Inner door | Glass door to view samples |
| Shelves | 3 to 12 (Height adjustable) |
| Safety | Audio / visual alarm for temperature deviation |
| Optional | Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels |
| Power supply | 220 Volts / 50 Hz |
 SIZE:
| Model | Dimensions (mm) | Volume (Litres) | Volume (Cu. Ft.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DR-SGC171 | 505 x 415 x 830 | 171 | 6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC209 | 600 x 550 x 910 | 300 | 10 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
STANDARD SIZE:
DR-SGC340 |
650 x 580 x 900 | 340 | 12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC400 | 700 x 640 x 900 | 400 | 14 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC580 | 775 x 775 x 970 | 580 | 20 |
