Designed for use in clinics, hospitals, and general practice settings
Compact and portable unit suitable for multi-patient environments
Supports quick and clear ECG acquisition with three simultaneous channels
User-friendly controls minimize training requirements
Offers reliable signal display and printed output for diagnostic review
Ideal for routine check-ups, stress testing prep, and emergency evaluations
Compatible with standard ECG lead configurations
Can operate in both stationary and mobile setups with optional cart integration
Clear waveform presentation supports accurate rhythm interpretation
Efficient operation aids in time-sensitive clinical decisions
Functional for pediatric, adult, and elderly patients
Supports low-maintenance operation for everyday use
3-channel simultaneous ECG acquisition
12-lead ECG recording
Integrated thermal printer for ECG report generation
Prints on 80mm wide paper
Built-in rechargeable battery with AC power operation
LCD display with functional navigation keys
Standard measurements: heart rate, PR/QRS/QT intervals, axes
Noise filters: baseline, muscle, AC interference
USB or SD card support for data export (model dependent)
Complies with medical safety and electromagnetic standards
Patient isolation and overvoltage protection included
Memory for limited number of ECG records
| Item Name | CO2 Incubator | |||||
| Model No. | DR-CO2-80UV | DR-CO2-80 | DR-CO2-80+ | DR-CO2-180UV | DR-CO2-180 | DR-CO2-180+ |
| Sterilization | UV | 140°C | 180°C | UV | 140°C | 180°C |
| Volume | 80L | 80L | 80L | 180L | 180L | 180L |
| Microprocessor-based controller | Proprietary algorithm to control CO2 and temperature | |||||
| Display | LCD touch display | |||||
| Temp control range | Ambient +5°C- 60°C | |||||
| Temp stability | ±0.1°C | |||||
| Temp field uniformity | ±0.3°C (at 37°C ) | |||||
| Timer function | 0 – 999hr 59 min. | |||||
| CO2 measurement principle | Infrared (IR) detection | |||||
| CO2 control range | 0-20% | |||||
| CO2 display resolution | 0.10% | |||||
| CO2 supply | 0.05~0.1MPa is recommended | |||||
| Relative Humidity | Ambient humidity ~95% at 37°C | |||||
| HEPA filtration | HEPA filters at the gas inlet, ISO 5 level, 5 minutes | |||||
| Temperature recovery time | ≤10 min (open door 30sec room temperature 25°C set value 37°C) | |||||
| O2 concentration recovery time | ≤5 min (open the door 30sec set value 5%) | |||||
| MOC | The inner chamber is made up of stainless steel and outer chamber with MS with powder coating | |||||
| Light | Florescent light | |||||
| Historical data storage | 250,000 messages | |||||
| Data export interface | USB interface | |||||
| Scalability | Up to 2 units can be stacked. | |||||
| Working environment temperature | 18~30°C | |||||
| Power supply | 230V±10%, 50~60Hz | |||||
| Inner Dimensions (L x D x H) mm | 450x450x450 | 550x600x600 | ||||
| Outer Dimensions (L x D x H) mm | 650x650x750 | 750x800x850 | ||||
| Temperature range | 5°C to 60°C |
| Temperature controller | Digital PID controller |
| Temperature accuracy | ±1% |
| Temperature sensor | PT-100 |
| Humidity range | 50% to 90% RH |
| Humidity controller | Digital PID controller |
| Humidity accuracy | ±3% |
| Light | 150-170 micromole/m2/sec |
| Light timer | 24×7 weekly digital timer |
| Construction | Double walled |
| Exterior | Mild steel powder coated |
| Interior | Stainless steel 304 |
| Outer door | Single or double solid doors with lock & key |
| Inner door | Glass door to view samples |
| Shelves | 3 to 12 (Height adjustable) |
| Safety | Audio / visual alarm for temperature deviation |
| Optional | Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels |
| Power supply | 220 Volts / 50 Hz |
 SIZE:
| Model | Dimensions (mm) | Volume (Litres) | Volume (Cu. Ft.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DR-SGC171 | 505 x 415 x 830 | 171 | 6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC209 | 600 x 550 x 910 | 300 | 10 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
STANDARD SIZE:
DR-SGC340 |
650 x 580 x 900 | 340 | 12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC400 | 700 x 640 x 900 | 400 | 14 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DR-SGC580 | 775 x 775 x 970 | 580 | 20 |
SPECIFICATIONS:
| Model No. | DR-800D |
| Center Max. Temp. | 825°C |
| Low Level Temp. | 480°C |
| Heating Speed | 20min (to max. temp.) |
| Max. Sterilize Diameter | Φ35mm |
| Heating Element Length | 100mm |
| Adjustable Angle | 75°~120° |
| Voltage | AC 220V / AC 110V, 50/60Hz |
| Power | 400W |
| Fuse | 250V, 3A/5A, Ф5×20 |
| Dimension (WxDxH) | 92 x 101 x 170mm |
| Net Weight | 1.1kg |
