Compact 5-part auto hematology analyzer
Offers 29 reportable parameters including 5-part WBC differential
Histogram and scattergram display for WBC, RBC, and PLT
10.4-inch TFT touch screen for intuitive operation
Automatic clog removal to ensure consistent performance
Built-in thermal printer for direct report printing
Open vial sampling for flexible workflow
Supports LIS connection for data integration
Storage capacity for 50,000 results including histograms and scattergrams
Available with optional barcode scanner and external printer
Simple user interface with multilingual support
Low reagent consumption to reduce operational cost
Reportable parameters: 29
Sample mode: Whole blood and pre-diluted
Throughput: 60 samples per hour
Display: 10.4″ TFT touch screen
Storage: 50,000 results with histograms and scattergrams
Printer: Built-in thermal printer
Connectivity: LIS supported
Optional: Barcode scanner and external printer
Automatic maintenance: Clog removal
Interface: User-friendly with multilingual support
Reagent system: Low consumption
| Air flow direction | Vertical and Horizontal |
|---|---|
| Air cleanliness | Class 100 |
| Construction | SS / Powder coated MS / GI sheet/ wooden with 18 gauge ss. |
| Sash (front door) | Manual/ Motorized sliding type (Acrylic transparent and tiffin glass) |
| Side panels | Acrylic /polycarbonate / SS |
| Air velocity | 0.4 m/s to 0.6 m/s/ 0.45m/sec |
| Illumination | Fluorescent or LED light/ UV light (800lux, glare-free) |
| Noise level | 65 ±5 dB |
| Power supply | 220 volts / 50 Hz |
| Air filtration |
|
| Air filtration |
|
| Optional |
|
SPECIFICATIONS:
| Temperature Range | 5°C to 60°C |
| Temperature accuracy | ±1°C |
| Temperature controller |
|
| Humidity Range | 40% to 95% RH |
| Humidity accuracy | ±3% RH |
| Humidity controller |
|
| Chamber Illumination | Fluorescent white light |
| Construction | Double walled |
| Insulation | PUF insulation |
| Exterior | Powder coated GI sheet |
| Interior | Stainless steel 304 |
| Door | Solid insulated door with lock and key |
| Inner door | Glass door fitted in steel frame |
| Shelves / trays | 2 to 5 steel wire mesh trays (height adjustable) |
| Air Circulation | Axial fan / blower |
| Refrigeration | CFC Free compressor with condenser, motor and relay complete unit |
| Humidity system |
|
| Optional |
|
| Volume (Liters) | Inner Chamber size (mm) | Trays | |
| 200 Liters | 600 x 600 x 600 | 2 | |
| 324 Liters | 600 x 600 x 900 | 2 | |
| 450 Liters | 600 x 600 x 1250 | 3 | |
| 600 Liters | 600 x 800 x 1250 | 3 | |
| 800 Liters | 800 x 800 x 1250 | 4 | |
| 1000 Liters | 800 x 800 x 1570 | 4 |
| ir flow direction | Vertical |
|---|---|
| Air cleanliness | Class 100 |
| Construction | SS / Powder coated MS / GI sheet/ wooden |
| Air flow direction | Vertical |
| Sash (front door) | Manual sliding type (Acrylic transparent) |
| Side panels | Acrylic / polycarbonate / SS |
| Air velocity | 0.45 m/s to 0.65 m/s |
| Illumination | Fluorescent or LED light |
| Noise level | 65 ±5 dB |
| Power supply | 220 volts / 50 Hz |
| Air filtration | Pre-Filter – 10 microns (washable) HEPA filter (0.3 Microns) |
| Standard fittings | Air / gas cock, Mains on/off switch, Light on/off switch UV Light on/off switch, Blower on/off switch |
| Optional | Motorized sliding door LCD display for velocity, time & lamp on/off UV Germicidal lamp UV Hour meter Magnehelic gauge Extra power outlet switch Foot rest Levelling legs for stand DOP HEPA filter testing |
