| Model no. | DR -80 |
|---|---|
| Volume | 450 L |
| Temperature | -40 TO -80℃ |
| Insulation thickness | 150mm |
| Cooling type | Direct cooling |
| Electric protection | I/B |
| Refrigerant | Mixed |
| Interior dimension | 552x635x1142mm |
| Consumption | 9.8kW. h/24h |
| Power | 1000W |
| Power Supply | 220V/50Hz |
| Climate class | N |
| Alarm type | Sound/ light |
| Exterior dimension | 855x965x1865mm |
| Package dimension | 960x1030x2030mm |
| Net weight | 205 kg |
| Gross weight | 255 kg |
| Optional function | Printer & recorder |
SPECIFICATIONS:
| Temperature Range | 5°C to 60°C |
| Temperature accuracy | ±1°C |
| Temperature controller |
|
| Humidity Range | 40% to 95% RH |
| Humidity accuracy | ±3% RH |
| Humidity controller |
|
| Chamber Illumination | Fluorescent white light |
| Construction | Double walled |
| Insulation | PUF insulation |
| Exterior | Powder coated GI sheet |
| Interior | Stainless steel 304 |
| Door | Solid insulated door with lock and key |
| Inner door | Glass door fitted in steel frame |
| Shelves / trays | 2 to 5 steel wire mesh trays (height adjustable) |
| Air Circulation | Axial fan / blower |
| Refrigeration | CFC Free compressor with condenser, motor and relay complete unit |
| Humidity system |
|
| Optional |
|
| Volume (Liters) | Inner Chamber size (mm) | Trays | |
| 200 Liters | 600 x 600 x 600 | 2 | |
| 324 Liters | 600 x 600 x 900 | 2 | |
| 450 Liters | 600 x 600 x 1250 | 3 | |
| 600 Liters | 600 x 800 x 1250 | 3 | |
| 800 Liters | 800 x 800 x 1250 | 4 | |
| 1000 Liters | 800 x 800 x 1570 | 4 |
| Construction | Economy Model | Double Walled Model | Triple Walled Model |
|---|---|---|---|
| MOC Exterior | Painted MS sheet | SS 304 (mirror finish) | SS 304 (mirror finish) |
| No. of walls | Two | Two | Three |
| Lid | Polished MS | SS 304 | SS 304 |
| Interior | SS 304 with silicon gasket | ||
| Working Pressure | 15-30 psi | ||
| Working Temp. | 121°C to 134°C | ||
| Controller | Auto set to 15psi & 121°C | ||
| Pressure display | Analogue dial gauge | ||
| Timer | Mechanical timer | ||
| Programmable | Programmable automatic start timer | ||
| Hydraulic tested | Hydraulically Tested up to 40 psi (ASME Guideline) | ||
| Lick lock | Single hand easy lock system for operating and closing | ||
| Program for heating sterilization, exhaust, warming and completion. | |||
| Basket | Stainless steel basket | Stainless steel basket | Not Required |
| Power supply | 220 Volts 50Hz | ||
| Standard Fittings | Low water indicator; Automatic pressure switch; Pedal lifting device Steam release valve; Water outlet valve; Spring loaded safety valve Power cable with three pin tops | ||
| Optional Accessories |
|
||
