Laminar Air Flow (Vertical)

Product Code: N/A

Categories: IMMUNO-HISTOPATHOLOGY, LABORATORY EQUIPMENTS, MICROBIOLOGY, MOLECULAR BIOLOGY

Side panels & front doors are made of 6 mm thick acrylic transparent plexi glass.
The highly efficient HEPA filter maintains the optimum cleanliness and purity.
The pre-filter fitted extends the life of HEPA filter drastically. Air drawn through pre-filter is made to pass through highly effective HEPA (High Efficiency Particular Air) filters having efficiency rating as high as 99.99% with cold DOP and 99.97% with hot DOP, thus retaining all air-borne particles of size 0.3 micron and larger.
Working area is illuminated by fluroescent lighting fitted to the unit.
The blower and motor assembly is statically and dynamically balanced of 1/5 H.P. capacity operates with minimum noise level.
Height of the working table provides comfortable “SIT DOWN” working position for the operator.
Supplied complete with S.S. Table Top, Transparent front door, Static Pressure Manometer. Built in U.V. Germicidal Light and Cock for gas, air or vacuum line, HEPA filters and pre-filter.
Supplied complete with cord & plug to work on Single Phase 220 / 230 volts A.C. supply

Related products

Air flow direction	Vertical and Horizontal
Air cleanliness	Class 100
Construction	SS / Powder coated MS / GI sheet/ wooden with 18 gauge ss.
Sash (front door)	Manual/ Motorized sliding type (Acrylic transparent and tiffin glass)
Side panels	Acrylic /polycarbonate / SS
Air velocity	0.4 m/s to 0.6 m/s/ 0.45m/sec
Illumination	Fluorescent or LED light/ UV light (800lux, glare-free)
Noise level	65 ±5 dB
Power supply	220 volts / 50 Hz
Air filtration	Pre-Filter – 5 microns (washable) HEPA filter (0.3 Microns)
Air filtration	Air / gas cock, Mains on/off switch, Light on/off switch UV Light on/off switch, Blower on/off switch
Optional	Motorized sliding door LCD display for velocity, time & lamp on/off UV Germicidal lamp UV Hour meter Magnehelic gauge Extra power outlet switchr Foot rest Levelling legs for stand DOP HEPA filter testing

Shaker Speed (20 – 250 RPM) (350,400 & 500 OPTIONAL)
Orbit Diameter	ø 25 mm
Accuracy	± 2% of maximum speed
Temperature range	5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available)
Resolution	0.1°C
Temp. accuracy	± 0.3˚C
Power supply	230V ± 10%, 50Hz

Parameters	Specifications
Temperature range	Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C
Temperature controller	Digital PID controller with SV & PV values
Temperature accuracy	±1%
Humidity	50% to 90%
Humidity controller	Digital PID controller with SV & PV values
Humidity accuracy	±3%
Illumination	3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX)
Light timer	24×7 weekly digital timer
Shelves	Stainless steel or chrome plated (Height adjustable)
Humidity system	SS boiler tank with immersion heater and automatic water replenishment by external tank
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz
