Constructed with a durable metal body and corrosion-resistant heating plate, the micro slide dryer ensures long-term reliability and easy maintenance. The compact design saves laboratory space while delivering accurate temperature control for dependable slide preparation.
Ideal for hospitals, diagnostic labs, research centers, and educational laboratories, the Micro Slide Dryer is an essential tool for achieving high-quality microscopic analysis.
Digital temperature control with display
Uniform heating surface for multiple slides
Quick and efficient slide drying
Compact and user-friendly design
Durable construction for long service life
Suitable for pathology, microbiology, and research laboratories
| Model | DR-RCB-6 | DR-RCB-12 |
|---|---|---|
| Make | DR Labs | DR Labs |
| Temp. Control Range | -20°C ~ 100°C | -20°C ~ 100°C |
| Temp. Resolution | 0.01°C | 0.01°C |
| Temp. Accuracy | ±0.05°C | ±0.05°C |
| Temp. Control | Microprocessor PID | Microprocessor PID |
| Display | LCD | LCD |
| Refrigeration Model | Air cooled refrigeration through compressor | Air cooled refrigeration through compressor |
| Refrigerant | R134A | R134A |
| Pump Circulation | Internal & External | Internal & External |
| Temp. Sensor | PT-100 | Â PT-100 |
| Pump Flow Rate | 6L/min | 6L/min |
| Tank Capacity | 6L | 12 L |
| Tank Size | 250 x 200 x 150 mm | 300 x 250 x 200 mm |
| Bath Opening | 180 x 140 mm | 235 x 160 mm |
| Bath Depth | 150 mm | 200 mm |
| Power Supply | AC 220 V / 50 Hz | AC 220 V / 50 Hz |
| Dimensions | 320 x 370 x 655 mm | 320 x 370 x 765 mm |
| Packing Dimensions & Weight | 530 x 450 x 800 mm & 44 kgs | 530 x 450 x 900 mm & 50 kgs |
| Chamber design | Round and Rectangular |
|---|---|
| Vacuum range | Up to -760 mmHg |
| Temperature range | Ambient+5°C to 150°C (Optional 200ºC) |
| Temperature sensor | PT100 |
| Temperature controller | Digital PID controller Display of SV & PV |
| Inner chamber | Hermetically welded stainless steel 304 sheet |
| External cabinet | Powder coated GI sheet |
| Door | Solid door with clamp & toughened glass window |
| Gasket | High temperature silicon gasket |
| Shelves | Removable SS shelves |
| Vacuum fittings | Vacuum valve / exhaust valves (Rubber hose) |
| Standard fittings | Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump |
| Power supply | 220 Volts 50Hz |
| Optional | KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump |
TECHNICAL PARAMETERS
Volume [L]: 220
Temp. Range [°C]: +5 to 60
Temp. Resolution [°C]: 0.1
Temp. Fluctuation at 37°C [°C]: ±0.5
Temp. Uniformity at 37°C [°C]: ±1
Rotation Rate [rpm]: 1~300
Rotation Accuracy [rpm]: ±1
Vibration Amplitude [mm]: Ø25
Timer Range [h]: 0~999
Number of Trays [pc]: 1 included ( 2 optional)
Power Supply [V, Hz]: 220, 50/60
Internal Dimensions W×D×H [mm]: 600x600x600
Housing Dimensions W×D×H [mm]: 755×870×1310
Tray Size W×D [mm]: 595x595mm
Standard Configuration [pcxml]: 16×250/500 or 9×1000 ml or 4×2000 ml
Net Weight [kg]: 220
| Shaker Speed (20 – 250 RPM) (350,400 & 500 OPTIONAL) | |
|---|---|
| Orbit Diameter | ø 25 mm |
| Accuracy | ± 2% of maximum speed |
| Temperature range | 5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available) |
| Resolution | 0.1°C |
| Temp. accuracy | ± 0.3˚C |
| Power supply | 230V ± 10%, 50Hz |
| Flasks | 12X12 | 16X16 | 18X18 | 24X24 |
| 50ml | 19 | 40 | 45 | 60 |
| 100ml | 12 | 16 | 18 | 24 |
| 250ml | 9 | 12 | 16 | 24 |
| 500ml | 4 | 6 | 8 | 10 |
| 1000ml | 2 | 3 | 3 | 5 |
| 2000ml | 1 | 2 | 2 | 4 |
