Specifications:

• Measurement Method: Manual

• Measurement Range: 0 – 300 mmHg

• Accuracy: ±2 mmHg

• Graduation: 2 mmHg increments

• Cuff Size: 22 – 42 cm

• Bladder Material: Latex or PVC, 2-tube system

• Bulb Type: Rubber inflation bulb with chrome-plated release valve

• Valve Type: Precision screw-type air control

• Mercury Column: Glass tube with metal scale backing

• Stand Type: Height-adjustable pole with 5-leg wheeled base

• Tubing: Extendable tubing

• Unit Height: Adjustable from 900 mm to 1300 mm

• Weight: 4.5 – 6 kg

• Operating Temperature: 10°C – 40°C

• Storage Temperature: -10°C – 50°C

• Non-return / Pressure Relief Valve: Minimizes risk of back flow of gases, blows off when pressure exceeds 125 Cm H₂O.
• Oxygen Flush: Emergency oxygen flush switch at table level to give 35 – 70 Ltrs/min for emergencies.
• O₂ failure Warning Alarm: Self activated electro-pneumatic audio visual warning device to indicate drop in O₂ pressure below 2.5 Bar.
• Anti-Hypoxic Guard: Mixing device to proportion the N₂O in such a way that minimum of 25% O₂ is always delivered from the rotameter.
• Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22 mm & 15 mm connections
• Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets
• Pressure Gauges: Large diameter

• Two Capacious drawers for keeping Anesthesia kit/accessories
• Extended platform at rear for two 5 litre. (Water Cap.) cylinder
• Large roller bearings 125mm , antistatic castors, for easy mobility and brakes
• Top tray provided at eye level for keeping monitoring equipment_ Hook for breathing circuit. Wipe clean stainless steel top.
• Provision to fit ventilator
• One CO₂ circle absorber system
• Unitized Rota meter block for oxygen & nitrous oxide with fine adjustment controls & colour coated knob and luminous back plate. Oxygen flow meter calibrated from 100cc/min to 10 litre./ Minute & Nitrous oxide flow meter from 200cc/min to 12 liters/min down Stream receipt of oxygen & (air 0 to 12 litre) (Optional)
• One vaporizer for Halothane / Isoflurane / Sevoflurane
• Non return cum blow off valve in circuit ensures that pressure does not hold-up beyond 200 cm. Water column & minimizes risk of back flow of gases.
• 60 psl outlet for driving ventilator
• Change over system open circuit or close circuit
• Emergency Oxygen flush valve at table level to give 35-60 litre/min for emergencies.
• Cylinder yokes: Pin indexed yokes two each of oxygen & nitrous oxide a 50 mm diameter, colour coded gauges fitted at convenient angle for better visibility & clarity.
• High efficiency regulators for reliability two each for O₂ & N₂O
• Vaporizer, Halothane / Isoflurane / Sevoflurane
