INDIATRANSPORTABLE MIXED GASINCUBATOR

Product Code: DR-GI-T48

Usage: For culturing embryos/oocytes in low oxygen, controlled temperature environment
Design: Compact, portable, humidified mixed gas incubator
Heating System: Dual zone heating – separate control for base and lid
Tube Capacity: Two heating blocks, each holding 12 × 5 ml tubes (24 tubes total) Gas Purge: Automatic gas purge when lid is closed
Humidity System: Built-in or external humidification flask included
Gas Type: Uses pre-mixed CO₂/O₂/N₂; multiple units can share one gas source Data Recording: 24-hour digital recording of temperature and gas flow Alarm System: Time-stamped alarms with event description
Display: Graphical data display for easy monitoring
Gas Tubing: Supplied with metal braided gas connection tube Temperature Range: ~5°C above ambient up to 40°C Temperature Accuracy: ±0.2°C; Control accuracy: ±0.1°C Humidity Range: 5% to 90% relative humidity
Power Supply: Universal: 100–240V AC, 50/60 Hz
Gas Accessories: Includes two-stage regulator and inline gas filter Fittings: Includes disconnect and fitting kit
Installation Base: Minimum 5 installations in India with 3 user reports from reputed institutions
