WALL MOUNT SUCTION APPARATUS/MEDICAL WARD VACUUM SUCTION UNITS

Air flow direction	Vertical and Horizontal
Air cleanliness	Class 100
Construction	SS / Powder coated MS / GI sheet/ wooden with 18 gauge ss.
Sash (front door)	Manual/ Motorized sliding type (Acrylic transparent and tiffin glass)
Side panels	Acrylic /polycarbonate / SS
Air velocity	0.4 m/s to 0.6 m/s/ 0.45m/sec
Illumination	Fluorescent or LED light/ UV light (800lux, glare-free)
Noise level	65 ±5 dB
Power supply	220 volts / 50 Hz
Air filtration	Pre-Filter – 5 microns (washable) HEPA filter (0.3 Microns)
Air filtration	Air / gas cock, Mains on/off switch, Light on/off switch UV Light on/off switch, Blower on/off switch
Optional	Motorized sliding door LCD display for velocity, time & lamp on/off UV Germicidal lamp UV Hour meter Magnehelic gauge Extra power outlet switchr Foot rest Levelling legs for stand DOP HEPA filter testing

Model	DR-RCB-6	DR-RCB-12
Make	DR Labs	DR Labs
Temp. Control Range	-20°C ~ 100°C	-20°C ~ 100°C
Temp. Resolution	0.01°C	0.01°C
Temp. Accuracy	±0.05°C	±0.05°C
Temp. Control	Microprocessor PID	Microprocessor PID
Display	LCD	LCD
Refrigeration Model	Air cooled refrigeration through compressor	Air cooled refrigeration through compressor
Refrigerant	R134A	R134A
Pump Circulation	Internal & External	Internal & External
Temp. Sensor	PT-100	PT-100
Pump Flow Rate	6L/min	6L/min
Tank Capacity	6L	12 L
Tank Size	250 x 200 x 150 mm	300 x 250 x 200 mm
Bath Opening	180 x 140 mm	235 x 160 mm
Bath Depth	150 mm	200 mm
Power Supply	AC 220 V / 50 Hz	AC 220 V / 50 Hz
Dimensions	320 x 370 x 655 mm	320 x 370 x 765 mm
Packing Dimensions & Weight	530 x 450 x 800 mm & 44 kgs	530 x 450 x 900 mm & 50 kgs

Parameter	DR-04WB	DR-06WB
Column	2 rows 4 holes	2 rows 6 holes
Temp. range	Rt+5~100℃
Temp. Resolution Ratio	0.1℃
Temp. Motion	±0.5℃
Temp. Uniformity	±1℃
Water sink	Stainless steel, surface electrolysis treatment
Outer shell	Cold rolled steel plate, surface electrostatic powder spray.
Heater	Stainless steel U-type heating tube
Power rating	1200 W
Temp. control mode	PID Controller
Timer	0 – 999 min（with timing function）
Timing function	Timing function, auto stop feature
Program	Optional: multi-section program control
Additional function	Deviation correction, menu key lock, power failure back-up, power-off parameter memory, PID-Tunable control
Sensor	Thermal resistor
Safety device	Over-temperature alarm, short-circuit protection.
Inner Chamber size(WLH)	305 x 305 x 130 mm	305 x 470 x 130 mm
Packing size (WLH)	415 x 415 x 275 mm	400 x 560 x 250 mm
Internal volume	12 L	18.6 L
Cover number per hole	∅120 mm
Power Supply 50/60Hz	220V, 50/60 Hz
Weight	6.5 kg	8 kg

Parameters	Specifications
Temperature range	Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C
Temperature controller	Digital PID controller with SV & PV values
Temperature accuracy	±1%
Humidity	50% to 90%
Humidity controller	Digital PID controller with SV & PV values
Humidity accuracy	±3%
Illumination	3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX)
Light timer	24×7 weekly digital timer
Shelves	Stainless steel or chrome plated (Height adjustable)
Humidity system	SS boiler tank with immersion heater and automatic water replenishment by external tank
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz
