Features:
High-luminance light source for clear, accurate viewing of X-ray films
Uniform and glare-free illumination to reduce eye strain and improve diagnostic clarity
Slim, compact design suitable for wall mounting or surface installation
Available in single, double, triple, or quad film viewer configurations
Built-in film sensor (optional) for auto-on functionality when film is inserted
Acrylic or opal glass viewing panel for even light diffusion
Low heat emission and long operational life using LED or fluorescent backlighting
Magnetic or clip-on film holders to secure films in place
Silent operation and minimal maintenance
| Type | Model No. | Description | Specifications | Features |
| LED X-Ray View Box (Standard) | DR-XRVS-STD | Available in single to four-film viewers; energy-efficient with film activation switch. | Brightness: 12,000–15,000 Lux; Power: AC100–240V; Brightness control: Rotary; Sizes: Single to Four Film. | Energy-efficient; Film activation switch; Wall-mountable. |
| LED X-Ray View Box (Slim Design) | DR-XRVS-SDN | Elegant slim design with aluminum body; high-quality viewing screen. | Sizes: Single to Four Film; Viewing area: 14″x17″ to 56″x17″; LED life: >100,000 hours; Power: AC110–220V. | Slim design; Uniform and soft light; Intensity regulator on panel. |
| LED X-Ray View Box (High-End) | DR-XRVS-HHD | Slim, durable, and energy-effective; suitable for MRI, CT, and X-ray images. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Quadruple Screen; LED life: 100,000 hours. | No UV emission; Magnetic nipper; 12-step digital dimmer; Automatic shutdown if no film inserted. |
| LED X-Ray View Box (Economy Version) | DR-XRVS-ENV | Slim and effective; external power adapter; suitable for budget-conscious settings. | Brightness: >6,500 Lux; Power: 15W–30W; Sizes: Single and Double Screen; LED life: 100,000 hours. | Energy-efficient; 10-step digital dimmer; External power adapter. |
| Flush Mounted LED X-Ray Viewer | DR-XRVS-FM | Designed for modular operation theatres; concealed wall installation. | Brightness: >10,000 Lux; Power: 15W–60W; Sizes: Single to Four Screen; LED life: 100,000 hours. | Seamless design; Maintains sterile environment; 6500K color temperature. |
| Dental LED X-Ray Viewer | DR-XRVS-DTL | Specifically for dental use; compact and lightweight. | Viewing area: 492×217 mm; Power: 10W; Brightness: >7,500 Lux; LED life: 100,000 hours. | Portable; Shockproof; Suitable for OPG films. |
| LED X-Ray View Box (Deluxe) | DR-XRVS-DLX | High brightness with excellent luminance uniformity; wall and table mounted. | Brightness: >10,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | Flicker-free; Inbuilt power supply; 2-year warranty; Film sensor and dimmer included. |
| LED X-Ray View Box (Premium) | DR-XRVS-PM | Slimmest design with high brightness; suitable for detailed image viewing. | Brightness: >7,500 Lux; Power: 30W–120W; Sizes: Single to Four Film; LED life: 100,000 hours. | 25mm thickness; Flicker-free; Inbuilt power supply; Film sensor and dimmer included. |
| LED X-Ray View Box (Economy) | DR-XRVS-ECN | Budget-friendly with adequate brightness; wall-mounted design. | Brightness: Up to 3,000 Lux; Power: 10W–20W; Sizes: Single and Double Film; LED life: 100,000 hours. | 70mm thickness; Flicker-free; Film sensor and dimmer included. |
| LED X-Ray View Box with Dimmer & Sensor | DR-XRVS-DMS | High-quality product with dimmer and sensor; trusted globally. | Brightness: 15,000 Lux; Power: 40W–160W; Sizes: Single to Four Film; LED life: 100,000 hours. | 45mm thickness; 7000K color temperature; Wall-mountable. |
| LED X-Ray Film View Box (Triple) | DR-XRVS-T3 | Triple film viewer with advanced features; suitable for various film types. | Brightness: 0–6,000 cd/m²; Power: 90W; Viewing area: 1080×422 mm; LED life: 100,000 hours. | PWM dimming system; LCD display; Automatic sensing function; Memory function. |
| LED X-Ray Film View Box (Single) | DR-XRVS-S1 | Single film viewer with compact design; suitable for various film types. | Brightness: 0–4,500 cd/m²; Power: 30W; Viewing area: 360×425 mm; LED life: 100,000 hours. | 25mm thickness; PWM dimming system; Automatic film activation; Eye protective feature. |
| Ultra Slim LED X-Ray View Box | DR-XRVS-UTS | Ultra-slim design with sensor and dimmer; suitable for detailed image viewing. | Brightness: 10,000 Lux; Power: 30W; Viewing area: 14″x17″; LED life: 100,000 hours. | 25mm thickness; 8000K color temperature; Wall-mountable. |
| Type: Configuration | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Operation Theatre Control Panel: Touchscreen PLC-Based | DR OTCP TSPLC | Digital control panel with 7” touchscreen and PLC for complete OT environment management. | Display: 7″ HMI Touch Control: PLC-based Power: 230V AC Interface: Modbus/BMS Mount: Flush wall-mounted |
– Centralized control – User-friendly interface – Programmable alerts – Password protection |
| Operation Theatre Control Panel: Membrane Type with Push Buttons | DR OTCP MB6F | Conventional push-button-based panel for managing 6 OT functions. | Functions: 6 (light, fan, temp, etc.) Material: SS304 front plate Indicators: LED Voltage: 230V AC |
– Cost-effective – Reliable and durable – Simple operation |
| Operation Theatre Control Panel: Hybrid Touch + Membrane | DR OTCP HTM | Combines membrane switches with a digital display for basic automation. | Display: Digital segment Switches: Membrane + tactile Enclosure: SS or powder-coated MS Size: 400×300 mm |
– Combines digital + manual – Semi-automated – Backlit buttons |
| Operation Theatre Control Panel: Glass Front Touchscreen | DR OTCP GFTS | Full glass front panel for high-end modular OTs with 10” touchscreen. | Display: 10” capacitive touch Material: Tempered glass Power: 230V Mounting: Recessed wall panel |
– Sleek design – Anti-bacterial surface – BMS compatible |
| Operation Theatre Control Panel: Nurse Station Interface Panel | DR OTCP NSIP | Wall-mounted panel allowing communication and control for nurses inside OT. | Functions: Intercom, Music, Timer, Lights Display: LED/Touchscreen Mount: Surface/flush Comms: Wired/wireless |
– Nurse call + communication – Music and clock integrated – Quick access panel |
| Operation Theatre Control Panel: HVAC & Light Integration Panel | DR OTCP HLI | Dedicated control unit for lighting and air handling unit inside OT. | Lighting: Dimming control HVAC: Temp display + setpoint Relay: 230V Display: Digital/Touch |
– HVAC & lighting in one unit – Alarm integration – SS housing |
| Operation Theatre Control Panel: Alarm & Timer Focused Unit | DR OTCP ATF | Compact unit focusing on elapsed time, clock, and critical OT alerts. | Timers: Elapsed, anesthesia Clock: 24hr format Alarms: OT door, gas Display: 3.5” digital LED |
– Ideal for retrofit – Easy wall installation – Low maintenance |
Digital Clock (24 hr)
Elapsed Time Indicator
Temperature & Humidity Display
HEPA Filter Status Alarm
Medical Gas Pressure Alarms
Lighting & Fan Control
Music System
Nurse Call / Intercom
Material: SS304, powder-coated CRCA, or toughened glass front
Mounting: Flush/recessed or wall-mounted
Interfaces: RS485, Modbus, BMS-ready, SCADA-compatible
| Type (with Configuration) | Model | Description | Typical Specifications | Key Features |
|---|---|---|---|---|
| Central Oxygen Supply System: Manifold + Bulk Tank | DR HGPS COSS | Supplies medical-grade oxygen to all zones from LOX tank or high-pressure cylinders. | Pressure: 4.2–5.0 bar Source: LOX/D-type Cylinders Pipeline: Degreased Copper (EN 13348) Alarm: Digital panel |
– Auto changeover manifold – Fire-safe ball valves – Pressure relief system – Audible/visual alarms |
| Medical Air System: Duplex Oil-Free Compressor + Air Dryer + Receiver | DR HGPS MAS | Delivers clean compressed air for respiratory use and surgical tools. | Output: 4.5–5.5 bar Compressor: 100% Oil-Free Scroll Receiver: 500 Ltr Dew Point: -40°C |
– Redundant operation – Bacteria filter & dryer – Noise-insulated cabinet – Pressure sensors |
| Vacuum System: Central Suction Pump + Receiver + Filter | DR HGPS VS | Provides centralized suction for OT, ICU, and critical care units. | Vacuum: -600 to -650 mmHg Pumps: 2x Rotary Vane (3 HP each) Receiver: 300 Ltr Filtration: Bacterial trap |
– Automatic pump alternation – Non-lubricated design – Overflow & noise control |
| Nitrous Oxide Supply: Manifold Cylinder Bank System | DR HGPS N2OS | Used in anesthesia delivery systems across OTs. | Pressure: 4.5–5.0 bar Cylinders: 12 Bank Piping: Degreased copper Alarm: Low pressure |
– Automatic switching – Safety relief valve – Medical color-coding (blue) |
| Medical Gas Alarm System: Area + Master Panels | DR HGPS MGAS | Monitors pressure levels and triggers alerts in all gas zones. | Zones: 7 Display: LED Digital Power: 230V AC Mounting: Wall surface/recessed |
– Audible & visual alert – Optional BMS integration – Real-time pressure monitoring |
| Bed Head Panel: Horizontal 3-Gas + Nurse Call + Power | DR HGPS BHP | Multi-utility horizontal panel for patient headwalls. | Length: 1200 mm Outlets: O2, Air, Vacuum Electrical: 3 sockets + nurse call Material: Aluminum |
– Modular, low maintenance – Gas & power segregation – LED night light (optional) |
| OT Pendant System: Double Arm with Gas, Electrical & Shelves | DR HGPS OTPS | Ceiling-mounted system for OT with movable arms and console. | Arm Length: 600+600 mm Gas Outlets: 6–8 types Load: Up to 200kg Rotation: 330° |
– 2-arm design for flexibility – Integrated gas & power – ICU & surgical variants |
| Anesthesia Gas Scavenging System: Active Type | DR HGPS AG2S | Extracts waste anesthetic gases to protect medical staff. | Flow Rate: 100–150 L/min Pressure: -20 to -40 mbar Filters: Inline HEPA Compliance: HTM 2022 |
– Staff exposure reduction – Low noise – Central or local exhaust options |
| Zone Valve Box: 5 Line with Monitoring Window | DR HGPS ZVB5 | Isolates gas lines for specific zones during servicing or emergency. | Lines: 5 Valve Type: ¼-turn brass Box: Powder-coated steel Labeling: Laser-etched |
– Transparent window – Lockable design – Color-coded tubing |
| Copper Medical Gas Piping Network: Degreased, EN Certified | DR HGPS CUMSPN | Backbone piping system for MGPS distribution across hospital floors. | Size: 10 mm to 54 mm Material: Copper EN 13348 Joint: Silver brazed Test Pressure: 1.5x Working Pressure |
– Smooth internal bore – Corrosion-resistant – Suitable for oxygen & vacuum |
