DR-BIPS2003 POWER SUPPLY

Parameter	DR-04WB	DR-06WB
Column	2 rows 4 holes	2 rows 6 holes
Temp. range	Rt+5~100℃
Temp. Resolution Ratio	0.1℃
Temp. Motion	±0.5℃
Temp. Uniformity	±1℃
Water sink	Stainless steel, surface electrolysis treatment
Outer shell	Cold rolled steel plate, surface electrostatic powder spray.
Heater	Stainless steel U-type heating tube
Power rating	1200 W
Temp. control mode	PID Controller
Timer	0 – 999 min（with timing function）
Timing function	Timing function, auto stop feature
Program	Optional: multi-section program control
Additional function	Deviation correction, menu key lock, power failure back-up, power-off parameter memory, PID-Tunable control
Sensor	Thermal resistor
Safety device	Over-temperature alarm, short-circuit protection.
Inner Chamber size(WLH)	305 x 305 x 130 mm	305 x 470 x 130 mm
Packing size (WLH)	415 x 415 x 275 mm	400 x 560 x 250 mm
Internal volume	12 L	18.6 L
Cover number per hole	∅120 mm
Power Supply 50/60Hz	220V, 50/60 Hz
Weight	6.5 kg	8 kg

Temperature range	5°C to 60°C
Temperature controller	Digital PID controller
Temperature accuracy	±1%
Temperature sensor	PT-100
Humidity range	50% to 90% RH
Humidity controller	Digital PID controller
Humidity accuracy	±3%
Light	150-170 micromole/m2/sec
Light timer	24×7 weekly digital timer
Construction	Double walled
Exterior	Mild steel powder coated
Interior	Stainless steel 304
Outer door	Single or double solid doors with lock & key
Inner door	Glass door to view samples
Shelves	3 to 12 (Height adjustable)
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz

Construction	Economy Model	Double Walled Model	Triple Walled Model
MOC Exterior	Painted MS sheet	SS 304 (mirror finish)	SS 304 (mirror finish)
No. of walls	Two	Two	Three
Lid	Polished MS	SS 304	SS 304
Interior	SS 304 with silicon gasket
Working Pressure	15-30 psi
Working Temp.	121°C to 134°C
Controller	Auto set to 15psi & 121°C
Pressure display	Analogue dial gauge
Timer	Mechanical timer
Programmable	Programmable automatic start timer
Hydraulic tested	Hydraulically Tested up to 40 psi (ASME Guideline)
Lick lock	Single hand easy lock system for operating and closing
	Program for heating sterilization, exhaust, warming and completion.
Basket	Stainless steel basket	Stainless steel basket	Not Required
Power supply	220 Volts 50Hz
Standard Fittings	Low water indicator; Automatic pressure switch; Pedal lifting device Steam release valve; Water outlet valve; Spring loaded safety valve Power cable with three pin tops
Optional Accessories	Fully stainless steel construction (GMP) Up to 134°C temperature range PID temperature controller cum timer with alarm (buzzer) PLC with HMI interface with data logging 21 CFR Part 11 software Thermal Printer Lower water cut-off
