DR-5100 NANO Drop / Microvolume Spectrophotomete

Sale!

Product Code: DR-5100

Categories: ANALYTICAL INSTRUMENTS, LABORATORY EQUIPMENTS, MOLECULAR BIOLOGY

Original price was: ₹434,500.00.Current price is: ₹395,000.00.

TECHNICAL SPECIFICATION

MODEL NO :DR-5100

Parameter	Specification	Parameter	Specification
★ 3 Light Course	0.05 mm (high concentration); 0.2 mm, 1.0 mm (ordinary concentration)	★ Absorbance	0.003 Abs (0.2 mm optical range)
★ Detectors	Ultraviolet silicon	★ Absorbance Accuracy	±1% (7.332 Abs at 260 nm)
★ Nucleic Acid Detection Range	15000 ng/µL (dsDNA)	★ Sample Volume Requirements	0.5–2 µL
★ Fluorescence Sensitivity	DsDNA: 0.5 pg/µL	★ Wavelength Range	260 nm, 280 nm
★ Fluorescence Linearity	<1.5%	★ Wavelength Accuracy	±1 nm within
★ OD600 Absorbance Range	0–6.000 Abs	★ Wavelength Reproducibility	<0.2 nm
★ OD600 Absorbance Stability	[0,3] <0.5%, [3,4] <2%	★ Wavelength Reproducibility	<0.2 nm
★ OD600 Absorbance Accuracy	[0,2] <0.005A, [2,3] <1%, [3,4] <2%	★ Sample Base Material	Quartz fiber and stainless steel
★ OD600 Absorbance Accuracy	[0,2] <0.005A, [2,3] <1%, [3,4] <2%	★ Testing Time	<6 s
★ OD600 Repeatability of Absorbance	[0,3] <0.5%, [3,4] <2%	★ Testing Time	<6 s
★ Noise Level	0.002 Arms (0A, 260 nm); between peaks 0.005 Arms, 260 nm	★ Power Consumption Standby	5 W
★ Absorbance Range	0.04–500A (Equivalent to 10 mm)	★ Data Output Method	USB
		★ Light Source	LED
		★ Power Adapter	24V DC
		★ Power Consumption	25 W

1 YEAR WARRANTY
(GST Extra)

Android OS

Related products

SPECIFICATIONS:

Temperature Range	5°C to 60°C
Temperature accuracy	±1°C
Temperature controller	Microprocessor PID controller Display of SV & PV Low / High buzzer
Humidity Range	40% to 95% RH
Humidity accuracy	±3% RH
Humidity controller	Microprocessor PID controller Display of SV & PV Low / High buzzer
Chamber Illumination	Fluorescent white light
Construction	Double walled
Insulation	PUF insulation
Exterior	Powder coated GI sheet
Interior	Stainless steel 304
Door	Solid insulated door with lock and key
Inner door	Glass door fitted in steel frame
Shelves / trays	2 to 5 steel wire mesh trays (height adjustable)
Air Circulation	Axial fan / blower
Refrigeration	CFC Free compressor with condenser, motor and relay complete unit
Humidity system	SS tank with heater Low water buzzer Auto filling water system
Optional	Stainless steel exterior (GMP) PLC based HMI controller w/ USB interface RS 485 interface 21 CFR part 11 software UV light Storage racks Validation port Caster wheels with brake IQ, OQ and PQ documents

Construction	Economy Model	Double Walled Model	Triple Walled Model
MOC Exterior	Painted MS sheet	SS 304 (mirror finish)	SS 304 (mirror finish)
No. of walls	Two	Two	Three
Lid	Polished MS	SS 304	SS 304
Interior	SS 304 with silicon gasket
Working Pressure	15-30 psi
Working Temp.	121°C to 134°C
Controller	Auto set to 15psi & 121°C
Pressure display	Analogue dial gauge
Timer	Mechanical timer
Programmable	Programmable automatic start timer
Hydraulic tested	Hydraulically Tested up to 40 psi (ASME Guideline)
Lick lock	Single hand easy lock system for operating and closing
	Program for heating sterilization, exhaust, warming and completion.
Basket	Stainless steel basket	Stainless steel basket	Not Required
Power supply	220 Volts 50Hz
Standard Fittings	Low water indicator; Automatic pressure switch; Pedal lifting device Steam release valve; Water outlet valve; Spring loaded safety valve Power cable with three pin tops
Optional Accessories	Fully stainless steel construction (GMP) Up to 134°C temperature range PID temperature controller cum timer with alarm (buzzer) PLC with HMI interface with data logging 21 CFR Part 11 software Thermal Printer Lower water cut-off

Model	DR-RCB-6	DR-RCB-12
Make	DR Labs	DR Labs
Temp. Control Range	-20°C ~ 100°C	-20°C ~ 100°C
Temp. Resolution	0.01°C	0.01°C
Temp. Accuracy	±0.05°C	±0.05°C
Temp. Control	Microprocessor PID	Microprocessor PID
Display	LCD	LCD
Refrigeration Model	Air cooled refrigeration through compressor	Air cooled refrigeration through compressor
Refrigerant	R134A	R134A
Pump Circulation	Internal & External	Internal & External
Temp. Sensor	PT-100	PT-100
Pump Flow Rate	6L/min	6L/min
Tank Capacity	6L	12 L
Tank Size	250 x 200 x 150 mm	300 x 250 x 200 mm
Bath Opening	180 x 140 mm	235 x 160 mm
Bath Depth	150 mm	200 mm
Power Supply	AC 220 V / 50 Hz	AC 220 V / 50 Hz
Dimensions	320 x 370 x 655 mm	320 x 370 x 765 mm
Packing Dimensions & Weight	530 x 450 x 800 mm & 44 kgs	530 x 450 x 900 mm & 50 kgs

Add to cart

SPECIFICATIONS:

Temperature range	Ambient to 60°C
Temperature accuracy	±0.2°C @37°C
Temperature controller	Dual display PID controller, Display SV & PV, Auto tuning feature
Temperature sensor	PT100
Inner chamber	SS 304
External cabinet	Powder coated GI sheet
Insulation	Glass wool
Door	Insulated door, Mechanical latch / clamp, Glass window
Heaters	Resistance wire heaters (Air Fin Heaters optional)
Shelves	SS wire mesh (removable)/ Shelves with holes for small instruments
Air circulation	Motorized blower / Axial fan
Standard fittings	Mains on/off switch, Load Indicator, Fan on/off switch
Power supply	220 Volts 50Hz
Optional	GMP construction (Inner & outer SS 304) PLC + HMI controller w/ USB interface 21 CFR Part 11 software Data logger w/ USB interface Thermal printer Inner chamber LED light
