Fully automated 5-part hematology analyzer
Offers 29 reportable parameters for comprehensive blood analysis
Features both histogram and scattergram for WBC, RBC, and PLT
Touch screen interface for smooth and intuitive operation
Built-in thermal printer for direct, on-the-spot result printing
Open vial sampling system for flexible and convenient sample handling
High throughput with the ability to process up to 60 samples per hour
Storage capacity for 100,000 patient results including histograms and scattergrams
Equipped with automatic clog removal system for minimal maintenance and improved reliability
Multilingual user interface to support operation in diverse clinical environments
Compact design to fit into laboratories with limited space
Optional barcode scanner and external printer supported
LIS connectivity supported for integration with lab information systems
Designed for efficient routine hematology testing in clinical laboratories
5-part WBC differential (WBC 5-DIFF)
29 reportable parameters
Sample type: Whole blood and pre-diluted
Throughput: 60 samples per hour
Display: Touch screen operation
Graphical output: Histogram and scattergram for WBC, RBC, and PLT
Built-in thermal printer included
Sample access: Open vial mode
Storage: Up to 100,000 results with histograms and scattergrams
Barcode scanner: Optional
External printer: Optional
Automatic clog removal system
LIS connectivity supported
User interface: Multilingual support
SPECIFICATIONS:
Temperature range | -10° C to -40°C |
---|---|
Temperature accuracy | ±0.5°C |
Temperature Uniformity | ±0.1°C |
Temperature controller | Dual display PID controller |
Temperature sensor | PT100 |
Inner chamber | SS 304 |
External cabinet | Powder coated GI sheet |
Insulation | Glass wool |
Door | Insulated door Mechanical latch / clamp |
Heaters | Resistance wire heaters |
Shelves | SS wire mesh (removable) |
Standard fittings | Mains on/off switch Load Indicator Fan on/off switch |
Power supply | 220 Volts 50Hz |
Optional | GMP construction (Inner & outer SS304) PLC + HMI controller w/ USB interface 21 CFR Part 11software Data logger w/ USB interface Thermal printer Inner chamber LED light |
Shaker Speed | (20 – 250 RPM) (350,400 & 500 OPTIONAL) |
---|---|
Orbit Dia | ø 25 mm |
Accuracy | ± 2% of maximum speed |
Temperature range | 5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available) |
Resolution | 0.1°C |
Temp. accuracy | ± 0.3 ̊C |
Power supply | 230V ± 10%, 50Hz |
Chamber design | Round and Rectangular |
---|---|
Vacuum range | Up to -760 mmHg |
Temperature range | Ambient+5°C to 150°C (Optional 200ºC) |
Temperature sensor | PT100 |
Temperature controller | Digital PID controller Display of SV & PV |
Inner chamber | Hermetically welded stainless steel 304 sheet |
External cabinet | Powder coated GI sheet |
Door | Solid door with clamp & toughened glass window |
Gasket | High temperature silicon gasket |
Shelves | Removable SS shelves |
Vacuum fittings | Vacuum valve / exhaust valves (Rubber hose) |
Standard fittings | Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump |
Power supply | 220 Volts 50Hz |
Optional | KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump |
