DR Labs DR- MS-300 is a compact magnetic stirrer with hot plate function. It has a temperature sensor to monitor your sample’s temperature and timer function.
SALIENT FEATURES:
• MICROPROCESSOR CONTROL: Operated by a digital control CUP. The CPU regulates the heating up to 300°C
•DIGITAL SPEED CONTROL: Stirring speed is also controlled by the CPU from the keyboard while the stirring speed is indicated on the bar graph.
•PROGRAMABLE: Operator can setup the objective temperature, hold temperature, stirring time and speed.
•AUTOMATIC TEMPERATURE CONTROL: Connect the temperature probe and place into glass container being stirred to measure and maintain the object temperature. Accuracy is ± 1°C.
STANDARD ACCESSORIES:
• Stir Bar
• Temperature Probe
• Instruction Manual
| Model | DR-MS-300 |
|---|---|
| Make | DR Labs |
| Display | LCD |
| Max. Volume (ml) | 2000 |
| Speed (RPM) | 1250 RPM |
| Speed Display Style | Graph (Not numeric value) |
| Top Plate Size | 135 x 135 mm |
| Plate Material | Steel |
| Max. Temp. (Plate surface) | ±1°C ( <100°C) ± 3° C (<300°C) |
| Temp. Accuracy | 0~50°C, Automatic |
| Timer | 999 Minutes |
| Power Supply | AC 220V / 50 Hz |
| Dimensions & Weight | 230 x 180 x 120 & 2.6 kgs |
| Parameters | Specifications |
|---|---|
| Temperature range | Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C |
| Temperature controller | Digital PID controller with SV & PV values |
| Temperature accuracy | ±1% |
| Humidity | 50% to 90% |
| Humidity controller | Digital PID controller with SV & PV values |
| Humidity accuracy | ±3% |
| Illumination | 3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX) |
| Light timer | 24×7 weekly digital timer |
| Shelves | Stainless steel or chrome plated (Height adjustable) |
| Humidity system | SS boiler tank with immersion heater and automatic water replenishment by external tank |
| Safety | Audio / visual alarm for temperature deviation |
| Optional | Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels |
| Power supply | 220 Volts / 50 Hz |
| DR-150PGC | 800 x 500 x 380 | 150 L |
| DR-250PGC | 550 x 450 x 1000 | 250 L |
| DR-350PGC | 550 x 550 x 1200 | 350 L |
| DR-450PGC | 800 x 600 x 1250 | 600 L |
| DR-800PGC | 1120 x 600 x 1200 | 800 L |
| DR-1000PGC | 1150 x 670 x 1300 | 1000 L |
| Model | DR-RCB-6 | DR-RCB-12 |
|---|---|---|
| Make | DR Labs | DR Labs |
| Temp. Control Range | -20°C ~ 100°C | -20°C ~ 100°C |
| Temp. Resolution | 0.01°C | 0.01°C |
| Temp. Accuracy | ±0.05°C | ±0.05°C |
| Temp. Control | Microprocessor PID | Microprocessor PID |
| Display | LCD | LCD |
| Refrigeration Model | Air cooled refrigeration through compressor | Air cooled refrigeration through compressor |
| Refrigerant | R134A | R134A |
| Pump Circulation | Internal & External | Internal & External |
| Temp. Sensor | PT-100 | Â PT-100 |
| Pump Flow Rate | 6L/min | 6L/min |
| Tank Capacity | 6L | 12 L |
| Tank Size | 250 x 200 x 150 mm | 300 x 250 x 200 mm |
| Bath Opening | 180 x 140 mm | 235 x 160 mm |
| Bath Depth | 150 mm | 200 mm |
| Power Supply | AC 220 V / 50 Hz | AC 220 V / 50 Hz |
| Dimensions | 320 x 370 x 655 mm | 320 x 370 x 765 mm |
| Packing Dimensions & Weight | 530 x 450 x 800 mm & 44 kgs | 530 x 450 x 900 mm & 50 kgs |
