DESCRIPTION:
Digital Orbital Shaker DR-300 is designed for shaking, mixing and aeration applications. It features adjustable speed control that provides gentle to vigorous agitation. The low noise and stable operation make it suitable for use in different laboratories like molecular biology, microbiology, immunology, chemistry, etc.
FEATURES:
APPLICATION:
Digital Orbital Shaker is suitable for cell culturing, staining/de-staining and general mixing in microbiology, chemistry, immunology, biochemistry, molecular biology, biopharmaceutical and biomedical laboratories.
SPECIFICATIONS:
| Model | DR-OS-300 | DR-OS-30 |
|---|---|---|
| Shaking Motion | Orbital | Orbital |
| Shaking orbit | 20mm | 40mm |
| Shaking Speed Range | {01-300 RPM (400-600 RPM Optional)} | 30-200 RPM |
| Timer Range | 99h 59 min digital timer | 99h 59 min digital timer |
| Operation | Continuous/ Timer based | Continuous/ Timer based |
| Display | 6×2 Numeric LCD | 6×2 Numeric LCD |
| Max Load Capacity | 10 Kg | 10 Kg |
| Platform Size & Type | 420mm x 420mm & Universal | 12” x 12” (inches) |
| Overall dimensions | W-410 x L-530 x H-200 with Lotus Clamp | W-410 x L-530 x H-200 with Lotus Clamp |
| Power Consumption | 10 W | 10 W |
| Power Supply | 220VAC-50Hz | 220-230 V \ 50-60Hz |
| Power | 150W | 150W |
| Weight | 20 Kg | 20 Kg |
| Model | DR-RCB-6 | DR-RCB-12 |
|---|---|---|
| Make | DR Labs | DR Labs |
| Temp. Control Range | -20°C ~ 100°C | -20°C ~ 100°C |
| Temp. Resolution | 0.01°C | 0.01°C |
| Temp. Accuracy | ±0.05°C | ±0.05°C |
| Temp. Control | Microprocessor PID | Microprocessor PID |
| Display | LCD | LCD |
| Refrigeration Model | Air cooled refrigeration through compressor | Air cooled refrigeration through compressor |
| Refrigerant | R134A | R134A |
| Pump Circulation | Internal & External | Internal & External |
| Temp. Sensor | PT-100 | PT-100 |
| Pump Flow Rate | 6L/min | 6L/min |
| Tank Capacity | 6L | 12 L |
| Tank Size | 250 x 200 x 150 mm | 300 x 250 x 200 mm |
| Bath Opening | 180 x 140 mm | 235 x 160 mm |
| Bath Depth | 150 mm | 200 mm |
| Power Supply | AC 220 V / 50 Hz | AC 220 V / 50 Hz |
| Dimensions | 320 x 370 x 655 mm | 320 x 370 x 765 mm |
| Packing Dimensions & Weight | 530 x 450 x 800 mm & 44 kgs | 530 x 450 x 900 mm & 50 kgs |
| Parameters | Specifications |
|---|---|
| Temperature range | Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C |
| Temperature controller | Digital PID controller with SV & PV values |
| Temperature accuracy | ±1% |
| Humidity | 50% to 90% |
| Humidity controller | Digital PID controller with SV & PV values |
| Humidity accuracy | ±3% |
| Illumination | 3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX) |
| Light timer | 24×7 weekly digital timer |
| Shelves | Stainless steel or chrome plated (Height adjustable) |
| Humidity system | SS boiler tank with immersion heater and automatic water replenishment by external tank |
| Safety | Audio / visual alarm for temperature deviation |
| Optional | Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels |
| Power supply | 220 Volts / 50 Hz |
| DR-150PGC | 800 x 500 x 380 | 150 L |
| DR-250PGC | 550 x 450 x 1000 | 250 L |
| DR-350PGC | 550 x 550 x 1200 | 350 L |
| DR-450PGC | 800 x 600 x 1250 | 600 L |
| DR-800PGC | 1120 x 600 x 1200 | 800 L |
| DR-1000PGC | 1150 x 670 x 1300 | 1000 L |
