MICROBIOLOGY

Model	DR-UV-1900	DR-UV-1900S
Make	DR Labs	DR Labs
Bandwidth	2 nm	0.5, 1.0, 2.0, 4.0 nm
Cell Holder	4 sample holder moveable	4 sample holder moveable
Optical System	Double Beam (1200 lines/mm Grating)	Double Beam (1200 lines/mm Grating)
Wavelength Range	190 ~ 1100 nm	190 ~ 1100 nm
Wavelength Accuracy	± 0.3 nm	± 0.3 nm
Wavelength Repeatability	± 0.2 nm	± 0.2 nm
Scanning Speed	High, Medium, Low (Max. 3000 nm/min)	High, Medium, Low (Max. 3000 nm/min)
Photometric Range	-4 ~ 4A, 0~999.9%T, 0~9999C, 1~9999F	-4 ~ 4A, 0~999.9%T, 0~9999C, 1~9999F
Photometric Accuracy (T)	± 0.3%T	± 0.3%T
Photometric Repeatability	0.2%T	0.2%T
Stability	± 0.001 A/h (700 nm, preheating for 1 hr)	± 0.001 A/h (700 nm, preheating for 1 hr)
Photometric Accuracy(A)	≤±0.002A(0~0.5A), ≤±0.004A(0.5~1A), ≤±0.006A(>2.0)	≤±0.002A(0~0.5A), ≤±0.004A(0.5~1A), ≤±0.006A(>2.0)
Baseline Flatness & noise	≤±0.001A/h	≤±0.001A/h
Stray Light	<0.05%T @ 220nm, 360nm	<0.05%T @ 220nm, 360nm
Data Output	USB	USB
Printer Port	Parallel Port	Parallel Port
Display	Touchscreen	Touchscreen
Lamps	D2 & Tungsten Halogen Lamp	D2 & Tungsten Halogen Lamp
Detector	Silicone Photodiode	Silicone Photodiode
Power Supply	AC 220V / 50Hz	AC 220V / 50Hz
Dimensions & Weight	650 x 450 x 220mm & 25kg	650 x 450 x 220mm & 25kg

Model	DR-TSI	DR-TSI-T
Display	4.3 inch touch screen (capacitive type)	4.3 inch touch screen (capacitive type)
Temperature control range	RT +5℃~105℃	0℃~105℃
Temperature uniformity	≤0.5℃	≤0.5℃
Timer range	1min~99h59min	1min~99h59min
Temperature control accuracy	±0.5℃(@30-50℃)	±0.5℃(@30-50℃)
Display accuracy	±0.1℃	±0.1℃
Shaking speed	200-3000rpm	200~3000rpm
Heating time (25-100℃)	≤15min (RT 20℃～30℃)	≤15min (RT 20℃～30℃)
Refrigeration time(detected at 25℃ ambient temperature)	—	≤20min (Ambient temperature ≤20℃: 20℃～0℃) ≤20min(Ambient temperature ≤25℃:RT～4°C) ≤20min (Ambient temperature ≤30℃:RT～10℃
Heating rate gear	Max; 3℃/min; 2°C/min;1℃/min; 0.1℃/min	Max; 3℃/min; 2°C/min;1℃/min; 0.1℃/min
Cooling rate gear	—	Max;1℃/min;0.5℃/min;0.1℃/min
Program number	50	50
External port	USB: program related, printer; 7Pin socket: thermo lid	USB: program related, printer; 7Pin socket: thermo lid
Shaking amplitude	3mm	3mm
Dimension(mm)	318x154x220	318×154×220
Blocks	0.5ml tubes, 2ml tubes & 96 well PCR Plate Optional: 0.2 1.5, 5, 15, 50 ml tubes, 384 well plates
Weight	10kg	10kg

ax. Speed	18500rpm
Max. RCF	23990×g
Max. Capacity	4×250ml
Time Range	0~99min
RPM/RCF Convert	Yes
Noise (dB)	≤ 55
Temperature	/
Acc/Dec	10 Kinds
Speed Accuracy	±20r/min
Temperature Accuracy	/
Voltage(V/Hz)	AC 220V/110V 50HZ/60HZ
Certificates	CE,ISO & Calibration report are available
Size (W x D x Hmm)	400×570×320mm
Net Weight(Kg)	40KG

Rotors :

NO	Rotor	Max Speed (rpm)	Max Volume (ml)	Max. RCF（×g
1	Swing Rotor(Round bucket)	4000	4x250ml	2880
2	Swing Rotor(Square bucket)	4000	4x250ml	2830
3	Swing Rotor	4000	4x16x7ml	2860
4	Swing Rotor	4000	4x16x5ml	2470
5	Swing Rotor	4000	4x13x10ml	2830
6	Microplate rotor(box type)	4000	2×3×96 well	2310
7	Microplate rotor(fame type)	4000	2×3×96 well	2270
8	Swing out rotor	5000	4×1×50ml	4730
9	Swing out rotor	5000	4×1×100ml	4730
10	Swing out rotor	4000	4×2×100ml	3020
11	Swing out rotor	4000	4×2×50ml	3020
12	Swing out rotor	4000	4×4×15ml	3020
14	Swing out rotor	4000	4×6×15ml	3200
15	Swing out rotor	4000	4×4×10/7ml	2770
16	Swing out rotor	4000	4×4×10/7ml	2770
17	Swing out rotor	4000	4×4×5ml adapter	2360
18	Swing out rotor	4000	4×6×10/7ml	2770
19	Swing out rotor	4000	4×6×5ml adapter	2360
20	Swing out rotor	4000	4×8×10/7ml	2770
21	Swing out rotor	4000	4×8×5ml adapter	2360
22	Swing out rotor	4000	4×12×5ml	2480
23	Swing out rotor	4000	4×12×7ml	2760
24	Swing out rotor	4000	4×10×10ml	2880
25	Fixed Rotor	14000	4×8PCR	12070
26	Fixed Rotor	13000	6×8PCR	16080
27	Fixed Rotor	14000	8×8PCR	13390
28	Fixed Rotor	13000	12×8PCR	17220
29	Fixed Rotor	14000	40×0.5ml	19960
18B-33	Fixed Rotor	18500	12×1.5ml	23990

Model No.	DR-DBI
Display	16×2 Alpha Numeric LCD
Temperature Range	Ambient to 70° C
Temperature Resolution	0.1° C
Inbuilt timer	0 to 99 Minute Timer
Android App	NA
Test Save Option	NA
Power	220 v ±10V AC
Dimensions (L x B x H)	275 x 187 x 94mm(Approx.)
Weight	1.5kg Approx.
Accessories	Instruction Manual

Model No.	DR-70	DR-60
Speed Range	300 – 1200rpm	200- 1200rpm
Shaking Orbit	3mm(horizontal)	2mm (horizontal)
Temp. Control Range	R.T+5°C – 70°C	R.T+5°C – 70°C
Temp. Setting Range	5°C – 70°C	5°C – 70°C
Temp. Stability	@37°C ±0.2°C	±0.2°C

Model	DR-C-108	DR-C-109	DR-C-110
Max. Speed	16,000 rpm	18500rpm	21000rpm
Max. RCF	20,600×g	23990×g	30910×g
Max. Capacity	6×100ml	4×180ml	4×800ml
Time Range	1–59h 59 min	0~59h59min	0~59h59min
RPM/RCF Convert	Yes	Yes	Yes
Noise (dB)	≤ 58	≤ 58	≤ 58
Temperature	-20°C to +40°C	-20℃~+40℃	-20℃~+40℃
Acc/Dec	10 Kinds	10 Kinds	10 Kinds
Speed Accuracy	±20 rpm	±20r/min	±20r/min
Temperature Accuracy	±1°C	±1°C	±1°C
Supported rotor type	Angle (27), swing (01), plate (01)	Swingout (07), Microplate (02), Angle (23), Vertical (02)	Swing (08), Microplate (03),Fixed rotor (35)
Dimension (LxWxHmm)	513×370×320 mm	570x600x340mm	513×370×320mm
Voltage(V/Hz)	AC 220V, 50Hz	AC 220V/110V, 50HZ/60HZ	AC 220V/110V 50HZ/60HZ
Certificates	CE, ISO	CE, ISO & Calibration report are available	CE, ISO &Calibration report are available

Model	DR-RC-101	DR-RC-102	DR-RC-103
Max. Speed	16,000 rpm	18500rpm	21000rpm
Max. RCF	20,600×g	23990×g	30910×g
Max. Capacity	6×100ml	4×180ml	4×800ml
Time Range	1–59h 59 min	0~59h59min	0~59h59min
RPM/RCF Convert	Yes	Yes	Yes
Noise (dB)	≤ 58	≤ 58	≤ 58
Temperature	-20°C to +40°C	-20℃~+40℃	-20℃~+40℃
Acc/Dec	10 Kinds	10 Kinds	10 Kinds
Speed Accuracy	±20 rpm	±20r/min	±20r/min
Temperature Accuracy	±1°C	±1°C	±1°C
Supported rotor type	Angle (27), swing (01), plate (01)	Swingout (07), Microplate (02), Angle (23), Vertical (02)	Swing (08), Microplate (03),Fixed rotor (35)
Dimension (LxWxHmm)	513×370×320 mm	570x600x340mm	513×370×320mm
Voltage(V/Hz)	AC 220V, 50Hz	AC 220V/110V, 50HZ/60HZ	AC 220V/110V 50HZ/60HZ
Certificates	CE, ISO	CE, ISO & Calibration report are available	CE, ISO &Calibration report are available

Models	DR-FD-10	DR-FD-10L	DR-FD-10LZ	DR-FD-10LZ+
Type	Standard chamber	Standard Chamber with 8 manifolds	TOP Press	TOP Press with standard chamber
Freeze drying area	0.12 ㎡
Ice Condenser capacity	3-4 kg /24h
Condenser temperature	-50°C /-80°C
Final Vacuum	< 10 Pa
Tray	Ф200 mm,4 layers, Spacing 70 mm
Bulk capacity	1.2 L, 10 mm thickness
Vial capacity Φ12mm	820 pcs
Vial capacity Φ16mm	460 pcs
Vial capacity Φ22mm	244 pcs
Condenser size	Ф215 mm, 140 mm deep
Drying chamber size	Ф260 × 430 mm
Vacuum Pump Flow Rate	2 L/S, 7.2 m³/h
Defrosting	Electric Defrosting
Cooling	Air cooling, ambient temperature ≤28°C
Voltage	220V /50 Hz, single phase
Power	970 W (-50°C) /1400 W (-80°C)
Dimension	610 x 450 x (370+430) mm (-50°C) 850 x 680 x (400+430) mm (-80°C)
Weight	70 kg (-50°C) 130 kg (-80°C)

Temperature range	-10° C to -40°C
Temperature accuracy	±0.5°C
Temperature Uniformity	±0.1°C
Temperature controller	Dual display PID controller
Temperature sensor	PT100
Inner chamber	SS 304
External cabinet	Powder coated GI sheet
Insulation	Glass wool
Door	Insulated door Mechanical latch / clamp
Heaters	Resistance wire heaters
Shelves	SS wire mesh (removable)
Standard fittings	Mains on/off switch Load Indicator Fan on/off switch
Power supply	220 Volts 50Hz
Optional	GMP construction (Inner & outer SS304) PLC + HMI controller w/ USB interface 21 CFR Part 11software Data logger w/ USB interface Thermal printer Inner chamber LED light

Model no.	DR -80
Volume	450 L
Temperature	-40 TO -80℃
Insulation thickness	150mm
Cooling type	Direct cooling
Electric protection	I/B
Refrigerant	Mixed
Interior dimension	552x635x1142mm
Consumption	9.8kW. h/24h
Power	1000W
Power Supply	220V/50Hz
Climate class	N
Alarm type	Sound/ light
Exterior dimension	855x965x1865mm
Package dimension	960x1030x2030mm
Net weight	205 kg
Gross weight	255 kg
Optional function	Printer & recorder

Shaker Speed (20 – 250 RPM) (350,400 & 500 OPTIONAL)
Orbit Diameter	ø 25 mm
Accuracy	± 2% of maximum speed
Temperature range	5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available)
Resolution	0.1°C
Temp. accuracy	± 0.3˚C
Power supply	230V ± 10%, 50Hz

Flasks	12X12	16X16	18X18	24X24
50ml	19	40	45	60
100ml	12	16	18	24
250ml	9	12	16	24
500ml	4	6	8	10
1000ml	2	3	3	5
2000ml	1	2	2	4

Air flow direction	Vertical and Horizontal
Air cleanliness	Class 100
Construction	SS / Powder coated MS / GI sheet/ wooden with 18 gauge ss.
Sash (front door)	Manual/ Motorized sliding type (Acrylic transparent and tiffin glass)
Side panels	Acrylic /polycarbonate / SS
Air velocity	0.4 m/s to 0.6 m/s/ 0.45m/sec
Illumination	Fluorescent or LED light/ UV light (800lux, glare-free)
Noise level	65 ±5 dB
Power supply	220 volts / 50 Hz
Air filtration	Pre-Filter – 5 microns (washable) HEPA filter (0.3 Microns)
Air filtration	Air / gas cock, Mains on/off switch, Light on/off switch UV Light on/off switch, Blower on/off switch
Optional	Motorized sliding door LCD display for velocity, time & lamp on/off UV Germicidal lamp UV Hour meter Magnehelic gauge Extra power outlet switchr Foot rest Levelling legs for stand DOP HEPA filter testing

NNER CHAMBER	SS 304 / 316/FRP COATING/PHENOLIC RESIN
EXTERIOR	Powder coated MS / Stainless Steel /GI
WORK TOP	SS 304 /Jet black granite
ILLUMINATION	Fluorescent tube light
BLOWER	Centrifugal exhaust blower (direct drive motor)
STANDARD FITTINGS	Water tap, sink with drainage system, electrical sockets and Canopy ventilation
OPTIONAL	FRP coating on inner walls Air foil Scrubber system Storage cabinet Caster wheels with brake Wet & dry service valves Certification (ASHRAE110- 1995 / EN-14175- 2003) Air Temperature indicator Flow Monitor IQ/OQ/PQ

Model	Dimensions
DR-FH-222	2 x 2 x 2 ft	610 x 610 x 610 mm
DR-FH-322	3 x 2 x 2 ft	914 x 610 x 610 mm
DR-FH-422	4 x 2 x 2 ft	1219 x 610 x 610 mm
DR-FH-522	5 x 2 x 2 ft	1524 x 610 x 610 mm
DR-FH-622	6 x 2 x 2 ft	1829 x 610 x 610 mm

Construction	Economy Model	Double Walled Model	Triple Walled Model
MOC Exterior	Painted MS sheet	SS 304 (mirror finish)	SS 304 (mirror finish)
No. of walls	Two	Two	Three
Lid	Polished MS	SS 304	SS 304
Interior	SS 304 with silicon gasket
Working Pressure	15-30 psi
Working Temp.	121°C to 134°C
Controller	Auto set to 15psi & 121°C
Pressure display	Analogue dial gauge
Timer	Mechanical timer
Programmable	Programmable automatic start timer
Hydraulic tested	Hydraulically Tested up to 40 psi (ASME Guideline)
Lick lock	Single hand easy lock system for operating and closing
	Program for heating sterilization, exhaust, warming and completion.
Basket	Stainless steel basket	Stainless steel basket	Not Required
Power supply	220 Volts 50Hz
Standard Fittings	Low water indicator; Automatic pressure switch; Pedal lifting device Steam release valve; Water outlet valve; Spring loaded safety valve Power cable with three pin tops
Optional Accessories	Fully stainless steel construction (GMP) Up to 134°C temperature range PID temperature controller cum timer with alarm (buzzer) PLC with HMI interface with data logging 21 CFR Part 11 software Thermal Printer Lower water cut-off

Parameter	DR-04WB	DR-06WB
Column	2 rows 4 holes	2 rows 6 holes
Temp. range	Rt+5~100℃
Temp. Resolution Ratio	0.1℃
Temp. Motion	±0.5℃
Temp. Uniformity	±1℃
Water sink	Stainless steel, surface electrolysis treatment
Outer shell	Cold rolled steel plate, surface electrostatic powder spray.
Heater	Stainless steel U-type heating tube
Power rating	1200 W
Temp. control mode	PID Controller
Timer	0 – 999 min（with timing function）
Timing function	Timing function, auto stop feature
Program	Optional: multi-section program control
Additional function	Deviation correction, menu key lock, power failure back-up, power-off parameter memory, PID-Tunable control
Sensor	Thermal resistor
Safety device	Over-temperature alarm, short-circuit protection.
Inner Chamber size(WLH)	305 x 305 x 130 mm	305 x 470 x 130 mm
Packing size (WLH)	415 x 415 x 275 mm	400 x 560 x 250 mm
Internal volume	12 L	18.6 L
Cover number per hole	∅120 mm
Power Supply 50/60Hz	220V, 50/60 Hz
Weight	6.5 kg	8 kg

Parameters	Specifications
Temperature range	Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C
Temperature controller	Digital PID controller with SV & PV values
Temperature accuracy	±1%
Humidity	50% to 90%
Humidity controller	Digital PID controller with SV & PV values
Humidity accuracy	±3%
Illumination	3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX)
Light timer	24×7 weekly digital timer
Shelves	Stainless steel or chrome plated (Height adjustable)
Humidity system	SS boiler tank with immersion heater and automatic water replenishment by external tank
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz

Model	DR-MC-15
Make	DR Labs
Speed Range	500~15000 RPM
Speed Increament	100 RPM
Max. RCF (x g)	15100, increment: 100
Speed Accuracy	±20
Rotor Capacity	0.2ml/0.5ml/1.5ml/ 2ml×12
Timer	Timer: 30s~99 min
Motor	Brushless DC Motor
Safety Features Noise	Door interlock, Over-speed detection, Over-temperature detection, Automatic internal diagnosis
Acceleration/Brake Time	Acceleration: 30s, Braking:10s
Power Supply	AC 220V / 50Hz
Dimension	256 x 225 x 155 mm & 6 kg
Weight	6 kgs

Model	DR-RCB-6	DR-RCB-12
Make	DR Labs	DR Labs
Temp. Control Range	-20°C ~ 100°C	-20°C ~ 100°C
Temp. Resolution	0.01°C	0.01°C
Temp. Accuracy	±0.05°C	±0.05°C
Temp. Control	Microprocessor PID	Microprocessor PID
Display	LCD	LCD
Refrigeration Model	Air cooled refrigeration through compressor	Air cooled refrigeration through compressor
Refrigerant	R134A	R134A
Pump Circulation	Internal & External	Internal & External
Temp. Sensor	PT-100	PT-100
Pump Flow Rate	6L/min	6L/min
Tank Capacity	6L	12 L
Tank Size	250 x 200 x 150 mm	300 x 250 x 200 mm
Bath Opening	180 x 140 mm	235 x 160 mm
Bath Depth	150 mm	200 mm
Power Supply	AC 220 V / 50 Hz	AC 220 V / 50 Hz
Dimensions	320 x 370 x 655 mm	320 x 370 x 765 mm
Packing Dimensions & Weight	530 x 450 x 800 mm & 44 kgs	530 x 450 x 900 mm & 50 kgs

DR-150PGC	800 x 500 x 380	150 L
DR-250PGC	550 x 450 x 1000	250 L
DR-350PGC	550 x 550 x 1200	350 L
DR-450PGC	800 x 600 x 1250	600 L
DR-800PGC	1120 x 600 x 1200	800 L
DR-1000PGC	1150 x 670 x 1300	1000 L

Item Name	CO2 Incubator
Model No.	DR-CO2-80UV	DR-CO2-80	DR-CO2-80+	DR-CO2-180UV	DR-CO2-180	DR-CO2-180+
Sterilization	UV	140°C	180°C	UV	140°C	180°C
Volume	80L	80L	80L	180L	180L	180L
Microprocessor-based controller	Proprietary algorithm to control CO2 and temperature
Display	LCD touch display
Temp control range	Ambient +5°C- 60°C
Temp stability	±0.1°C
Temp field uniformity	±0.3°C (at 37°C )
Timer function	0 – 999hr 59 min.
CO2 measurement principle	Infrared (IR) detection
CO2 control range	0-20%
CO2 display resolution	0.10%
CO2 supply	0.05~0.1MPa is recommended
Relative Humidity	Ambient humidity ~95% at 37°C
HEPA filtration	HEPA filters at the gas inlet, ISO 5 level, 5 minutes
Temperature recovery time	≤10 min (open door 30sec room temperature 25°C set value 37°C)
O2 concentration recovery time	≤5 min (open the door 30sec set value 5%)
MOC	The inner chamber is made up of stainless steel and outer chamber with MS with powder coating
Light	Florescent light
Historical data storage	250,000 messages
Data export interface	USB interface
Scalability	Up to 2 units can be stacked.
Working environment temperature	18~30°C
Power supply	230V±10%, 50~60Hz
Inner Dimensions (L x D x H) mm	450x450x450			550x600x600
Outer Dimensions (L x D x H) mm	650x650x750			750x800x850

Temperature range	5°C to 60°C
Temperature controller	Digital PID controller
Temperature accuracy	±1%
Temperature sensor	PT-100
Humidity range	50% to 90% RH
Humidity controller	Digital PID controller
Humidity accuracy	±3%
Light	150-170 micromole/m2/sec
Light timer	24×7 weekly digital timer
Construction	Double walled
Exterior	Mild steel powder coated
Interior	Stainless steel 304
Outer door	Single or double solid doors with lock & key
Inner door	Glass door to view samples
Shelves	3 to 12 (Height adjustable)
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz

Volume (Liters)	Inner Chamber size (mm)	Trays
200 Liters	600 x 600 x 600	2
324 Liters	600 x 600 x 900	2
450 Liters	600 x 600 x 1250	3
600 Liters	600 x 800 x 1250	3
800 Liters	800 x 800 x 1250	4
1000 Liters	800 x 800 x 1570	4

Shaker Speed	(20 – 250 RPM) (350,400 & 500 OPTIONAL)
Orbit Dia	ø 25 mm
Accuracy	± 2% of maximum speed
Temperature range	5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available)
Resolution	0.1°C
Temp. accuracy	± 0.3 ̊C
Power supply	230V ± 10%, 50Hz

Chamber design	Round and Rectangular
Vacuum range	Up to -760 mmHg
Temperature range	Ambient+5°C to 150°C (Optional 200ºC)
Temperature sensor	PT100
Temperature controller	Digital PID controller Display of SV & PV
Inner chamber	Hermetically welded stainless steel 304 sheet
External cabinet	Powder coated GI sheet
Door	Solid door with clamp & toughened glass window
Gasket	High temperature silicon gasket
Shelves	Removable SS shelves
Vacuum fittings	Vacuum valve / exhaust valves (Rubber hose)
Standard fittings	Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump
Power supply	220 Volts 50Hz
Optional	KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump

Model No.	DR-800D
Center Max. Temp.	825°C
Low Level Temp.	480°C
Heating Speed	20min (to max. temp.)
Max. Sterilize Diameter	Φ35mm
Heating Element Length	100mm
Adjustable Angle	75°~120°
Voltage	AC 220V / AC 110V, 50/60Hz
Power	400W
Fuse	250V, 3A/5A, Ф5×20
Dimension (WxDxH)	92 x 101 x 170mm
Net Weight	1.1kg

Category	DR-B2
External Size (WDH)	13837752250 mm
Internal Size (WDH)	1210600660 mm
Tested Opening	Safety height 10″
Max Opening	470 mm
Airflow Volume (Exhaust)	100%: 1320 m³/h (776 cfm)
Front Window	Motorized;Two-layer laminated toughened glass ≤6mm, Anti-UV
Filter	ULPA,99.9995% efficiency at 0.12μm (02), filter life indicator
Filter Guard Type	Aluminum alloy frame
Noise	NSF 49 ≤60 dB
Illumination	≥1000 Lux
Socket	2, Total consumption ≤500W
Display	Touch screen
Tap	Water tap1, Gas tap1
Power Supply	AC220V,50/ 60Hz
Consumption	400W
Alarm	Abnormal airflow velocity; Filter replacement; Front window at unsafe height
Blower	One ECM motor, 230V AC; Speed adjustable, high efficiency and low power consumption
Material	Working area: 304 stainless steel Frame,Decorative Plate: cold-rolled steel with anti- bacteria powder coating
UV Lamp	30W
Germicidal UV Lamp	Emission of 253.7 nanometers for most efficient decontamination
Certification	NSF 49
Illuminating Lamp	LED lamp, 20W*2
Standard Accessory	LED lamp2, UV lamp2, Base stand, SS water tap1, Gas tap1, Drain valve, Waterproof socket*2
Optional Accessory	Armrest, Airflow tester, Formalin fumigation sterilizer, Infrared sterilizer, exhaust duct
Package Size (WDH)	154010801900 mm
Gross Weight	340 kg

Temperature range	Ambient to 60°C
Temperature accuracy	±0.2°C @37°C
Temperature controller	Dual display PID controller, Display SV & PV, Auto tuning feature
Temperature sensor	PT100
Inner chamber	SS 304
External cabinet	Powder coated GI sheet
Insulation	Glass wool
Door	Insulated door, Mechanical latch / clamp, Glass window
Heaters	Resistance wire heaters (Air Fin Heaters optional)
Shelves	SS wire mesh (removable)/ Shelves with holes for small instruments
Air circulation	Motorized blower / Axial fan
Standard fittings	Mains on/off switch, Load Indicator, Fan on/off switch
Power supply	220 Volts 50Hz
Optional	GMP construction (Inner & outer SS 304) PLC + HMI controller w/ USB interface 21 CFR Part 11 software Data logger w/ USB interface Thermal printer Inner chamber LED light

Product Categories

Rotors :

Related products

SPECIFICATIONS:

TECHNICAL SPECIFICATIONS:

STANDARD SIZE/DIMENSION:

Related products

Related products

TECHNICAL PARAMETERS:

SPECIFICATIONS:

SPECIFICATIONS:

WhatsApp

EMAIL ID

Skype

Useful Links

Follow on us
