★ Excitation Source 150W xenon lamp (Hamamatsu)

★ Excitation Wavelength 200nm~900nm

★ Emission Wavelength 200nm~900nm

★ Excitation Slit 10nm

★ Emission Slit 10nm

★ Wavelength Accuracy ±1.0nm

★ Wavelength Repeatability 0.5nm

★ Signal-to-Noise Ratio Raman peak of water (P-P)
S/N≥150 (10nm Slit) S/N≥800 (RMS)

★ Limit ≤1×10⁻¹⁰ g/ml (Quinine Sulfate Solution)

★ Linearity γ≥0.995

★ Peak Repeatability ≤1.5%

★ Stability (10min) Zero Drift : ±0.3, Value Limit : ±1.5%

★ Wavelength Scan Speed Multi-speed Level, Maximum at 48000nm/min

★ Photometric Quantity Range 0.00-10000.00

★ Data Transportation USB 2.0

★ Power 200W

★ Power Source AC~220V, 50Hz

★ Instrument Dimension 380×445×310 (mm)

Features:

Main FeaturesHigh sensitivity: based on high efficiency optical design and weak signal detection technology, the water Raman peak signal to noise ratio can be greater than 150(P-P).

Wide Spectral measurement range: using a double monochromator design, excitation and emission wavelength range covering 200 nm to 900 nm, meet the needs of most fluorescence analysis.

Excitation light path monitoring system: instrument is equipped with excitation light dual beam ratio monitoring system to ensure the fluorescence signal high and stable.

High quality assurance: using Hamamatsu’s high quality Xenon light source and photometric multiplier tube detectors and instruments to provide sufficient light intensity signal and the detection sensitivity.
