Features:
Wall-mounted design with adjustable height (850 to 1200 mm)
Stainless steel AISI-304 polished construction
Corner-free construction to prevent dirt accumulation
Integrated central sink (approx. 400 x 400 mm)
Medical hot/cold faucet with vacuum switch
Medical shower with hydraulic hose and PVC cover
Dissection trays (perforated, removable, 1 mm holes x 2 mm)
Formalin sink with pre-filter, cover, and automatic dispensing pedal
Formalin dispenser tap and mixer
Polyethylene cutting board included
2 storage drawers and 2 shelves
4 electric sockets for equipment
Magnetic instrument support board and instrument holding shelf
Waste bucket and waste disposal system included
Station-trolley anchoring system
Magnetic support for tools
Careneed inferior base and leveling feet
UVC disinfection lighting with eye protection
LED lighting for work area
Ducts for external ventilation connection
Emergency automatic ventilation for formalin spill
Supplied with ISO 9001 and ISO 13485 certification
Specifications:
Stainless steel thickness: 1.5–2 mm
Dimensions: approx. 2400 L x 800 W x 1750 H mm
Ventilation system with centrifugal electro-fan motors
Adjustable suction speed, max capacity 1404 m³/h
Aluminium axis filters with potassium permanganate for formaldehyde
Touch screen control for ventilation and filter monitoring
Filter life control with notification at 800 hrs
Visual alarms and ON/OFF lighting controls
Displays splash shield control, ventilation speed %, filter hours
Water-tight safety covers on switches
Electrical supply: 220V ±20V, 50Hz
Formalin tank storage with ventilated lower enclosure
Height adjustable work area with 350 mm range
Supplied with 2 perforated removable trays (handling holes at corners)
Material: High-density polyethylene or closed-cell foam
Components:
– 2 head blocks
– 1 base pad with Velcro
– 2 head straps (forehead and chin)
Weight: Approx. 1.5 – 2.5 kg
Straps: Adjustable with hook-and-loop fasteners
Radiolucent: Yes (X-ray, CT, MRI compatible)
Waterproof: Yes
Finish: Non-absorbent, easy-wipe surface
Material: Aluminum alloy or high-strength polymer (X-ray translucent options available)
Weight Capacity: 150 – 180 kg
Net Weight: Approx. 7 – 9 kg
Locking Mechanism: Snap or twist-lock at head and foot ends
Handles: Integrated or extended grip handles on both halves
Finish: Anodized or powder-coated, corrosion-resistant
Accessories (Included/Optional): Safety belts or restraint straps
Backrest Adjustment: 0° – 75°
Knee Rest Adjustment: 0° – 35°
Platform Type: Four-section, perforated CRCA steel platform
Frame Material: CRCA steel, pre-treated and powder coated
Head & Foot Panels: Mild steel (standard), ABS (optional)
Side Rails: Optional (fixed or collapsible, aluminum or steel)
Castors: 100 – 125 mm diameter, 2 with brakes
Crank System: 2 manual cranks with foldable handles
Safe Working Load: 180 – 200 kg
Finish: Epoxy powder coated, corrosion-resistant
Accessories Included: IV pole provision, drainage bag hooks
Light Source: High-efficiency LED
Color Temperature: Approx. 5500K – 6500K (natural white light)
Illuminance: 50,000 – 100,000 lux at a working distance of 30 cm
Battery Type: Rechargeable lithium-ion battery
Battery Life: Typically 4 – 8 hours per full charge
Charging Time: 3 – 4 hours
Spot Size: Adjustable from ~10 mm to 100 mm at 30 cm
Headlight Weight: Around 200 – 350 grams (without battery)
LED Lifespan: Up to 50,000 hours
Power Source: AC adapter with battery pack
Material: Medical-grade plastic and metal components
Usage Environment: Clinical, surgical, dental, and veterinary settings
