• A) Auto mode-3, 3+R with medians, 3+R with  Medians + Axis + measurements & interpretation
• B) Manual mode -3 channel three different lead selected from keypad

• Upgraded integrated Circle Absorber, With twins large volume CO₂ absorbing Efficiency
• With non-return respiratory valve and expiratory valve on it avoid gas back flowing
• With APL valve on it, the airway pressure could be adjusted freely With ‘Manual/Ventilation
• Switch On it, easily and quickly change
• One vaporizer /isoflurane /halothane / Sevoflurane
• Rust Proof Epoxy Coated High Strength Frame Pipeline Attachment for O₂, N₂O
• One yoke for O₂ (5 ltrs) cylinder and one for N₂O (5ltrs) cylinder
• Select tec bar with provision to mount 2 Vaporizers

Technical Specifications

• Storage Space: Three spacious drawers to hold essential anesthesia kit and accessories.
• Castors: Large roller bearing anti-static castors with front brakes.
• Electronic gas mixing with electronic Hypoxia guard.
• Audio Visual alarm for failure.
• Electronic and mechanical Flush 30-70 Lpm Flow.
• System pressure relief at 125 cm.
• Cylinder Yokes: Color coded gas specific (pin indexed) yokes with sliding stainless steel clamping bars for easy handling.
• Holding 1 (One) each for and , 5 Ltr water capacity cylinders.
• Non-return / Pressure Relief Valve: Minimises risk of back flow of gases, blows off when pressure exceeds 125 cm.
• Oxygen Flush: Electronic and mechanical flush 30-70 LPM flow.
• Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22 & 15 mm connections.
• Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets one each for and Air.
• I n c a s e o f drop in piped gas pressure the pin index cylinders take over automatically.
• Hypoxia Guard: Electronic/ Digital Hypoxia guard.
• Gas Mixing: Electronic flowmeter for the graphical representation of and Air.
• Selectatec Brackets: Twin Selectatec Block.
• Breathing Circuits: Bains Circuit & Circle Absorber Y-Circuit provided as standard.
