Specifications:

• Measurement Method: Manual

• Measurement Range: 0 – 300 mmHg

• Accuracy: ±2 mmHg

• Graduation: 2 mmHg increments

• Cuff Size: 22 – 42 cm

• Bladder Material: Latex or PVC, 2-tube system

• Bulb Type: Rubber inflation bulb with chrome-plated release valve

• Valve Type: Precision screw-type air control

• Mercury Column: Glass tube with metal scale backing

• Stand Type: Height-adjustable pole with 5-leg wheeled base

• Tubing: Extendable tubing

• Unit Height: Adjustable from 900 mm to 1300 mm

• Weight: 4.5 – 6 kg

• Operating Temperature: 10°C – 40°C

• Storage Temperature: -10°C – 50°C

Specifications:

• Measurement Parameters:
  – SpO₂ (Oxygen Saturation): 0% – 100%
  – Pulse Rate: 30 – 250 bpm

• SpO₂ Accuracy: ±2% (for 70% – 100% range)

• Pulse Rate Accuracy: ±2 bpm or ±2%

• Display Type: Large LED or TFT screen

• Waveform Display: Plethysmograph (real-time pulse waveform)

• Alarm Functions: Adjustable thresholds for SpO₂ and PR, with sound and visual indicators

• Power Supply:
  – AC mains (100 – 240V, 50/60 Hz)
  – Built-in rechargeable battery

• Battery Backup: 4 – 8 hours of operation

• Data Storage: Up to 72 hours or more

• Connectivity: USB / RS232 / LAN

• Weight: ~1.5 – 3 kg

• Operating Environment:
  – Temperature: 5°C – 40°C
  – Humidity: ≤85% non-condensing

• Non-return / Pressure Relief Valve: Minimizes risk of back flow of gases, blows off when pressure exceeds 125 Cm H₂O.
• Oxygen Flush: Emergency oxygen flush switch at table level to give 35 – 70 Ltrs/min for emergencies.
• O₂ failure Warning Alarm: Self activated electro-pneumatic audio visual warning device to indicate drop in O₂ pressure below 2.5 Bar.
• Anti-Hypoxic Guard: Mixing device to proportion the N₂O in such a way that minimum of 25% O₂ is always delivered from the rotameter.
• Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22 mm & 15 mm connections
• Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets
• Pressure Gauges: Large diameter
