Features:
Three-section bed design for antenatal, delivery, and postnatal care
Telescopic adjustable backrest and leg section for varied birthing positions
Removable foot-end section to convert into delivery mode
Height adjustment via telescopic mechanism for caregiver ease
Cushioned top with water-resistant, easy-to-clean mattress
Adjustable lithotomy leg supports with straps
Foldable side safety rails for patient security
Integrated IV rod and provision for accessories
Strong and stable structure with both anti-skid rubber shoes and smooth-rolling castors with brakes
Suitable for maternity wards, labor rooms, and delivery centers
Specifications:
Frame material: Mild steel or stainless steel with epoxy powder coating
Mattress sections: Three-section, foam-padded with waterproof cover
Overall dimensions: Approx. 1800–2000 x 600–700 mm
Height adjustment range: Approx. 600–850 mm
Backrest angle: Adjustable up to 70°
Leg section: Adjustable and/or detachable
Lithotomy poles: Height and angle adjustable with padded supports
Base: With anti-skid rubber shoes and/or lockable castors
Load capacity: Up to 150–180 kg
Finish: Epoxy powder coated or stainless steel polished
Weight: Approx. 60–80 kg
Measurement Method: Oscillometric manual inflation
Measurement Range:
– Systolic: 60 – 260 mmHg
– Diastolic: 40 – 199 mmHg
– Pulse Rate: 40 – 180 bpm
Accuracy:
– Pressure: ±3 mmHg
– Pulse: ±5%
Display Type: Large LCD with backlight
Cuff Size: 22 – 42 cm
Auto Power Off: After 1 minute of inactivity
Operating Temperature: 5°C – 40°C
Humidity Range: 15% – 85% RH non-condensing
Measurement Method: Manual
Measurement Range: 0 – 300 mmHg
Accuracy: ±2 mmHg
Graduation: 2 mmHg increments
Cuff Size: 22 – 42 cm
Bladder Material: Latex or PVC, 2-tube system
Bulb Type: Rubber inflation bulb with chrome-plated release valve
Valve Type: Precision screw-type air control
Mercury Column: Glass tube with metal scale backing
Stand Type: Height-adjustable pole with 5-leg wheeled base
Tubing: Extendable tubing
Unit Height: Adjustable from 900 mm to 1300 mm
Weight: 4.5 – 6 kg
Operating Temperature: 10°C – 40°C
Storage Temperature: -10°C – 50°C
Measurement Method: Manual
Measurement Range: 0 – 300 mmHg
Accuracy: ±2 mmHg
Graduation: 2 mmHg increments
Cuff Size: 22 – 42 cm
Bladder Material: Latex or PVC, 2-tube design
Bulb: Rubber inflation bulb with air-release valve
Valve Type: Chrome-plated screw-type
Mercury Column: Glass tube with metal scale backing
Base Material: Powder-coated metal or ABS plastic
Weight: 2.5 – 3 kg
Operating Temperature: 10°C – 40°C
Storage Temperature: -10°C – 50°C
Technical Specifications
