Specifications:

• Measurement Method: Manual

• Measurement Range: 0 – 300 mmHg

• Accuracy: ±2 mmHg

• Graduation: 2 mmHg increments

• Cuff Size: 22 – 42 cm

• Bladder Material: Latex or PVC, 2-tube design

• Bulb: Rubber inflation bulb with air-release valve

• Valve Type: Chrome-plated screw-type

• Mercury Column: Glass tube with metal scale backing

• Base Material: Powder-coated metal or ABS plastic

• Weight: 2.5 – 3 kg

• Operating Temperature: 10°C – 40°C

• Storage Temperature: -10°C – 50°C

• Two Capacious drawers for keeping Anesthesia kit/accessories
• Extended platform at rear for two 5 litre. (Water Cap.) cylinder
• Large roller bearings 125mm , antistatic castors, for easy mobility and brakes
• Top tray provided at eye level for keeping monitoring equipment_ Hook for breathing circuit. Wipe clean stainless steel top.
• Provision to fit ventilator
• One CO₂ circle absorber system
• Unitized Rota meter block for oxygen & nitrous oxide with fine adjustment controls & colour coated knob and luminous back plate. Oxygen flow meter calibrated from 100cc/min to 10 litre./ Minute & Nitrous oxide flow meter from 200cc/min to 12 liters/min down Stream receipt of oxygen & (air 0 to 12 litre) (Optional)
• One vaporizer for Halothane / Isoflurane / Sevoflurane
• Non return cum blow off valve in circuit ensures that pressure does not hold-up beyond 200 cm. Water column & minimizes risk of back flow of gases.
• 60 psl outlet for driving ventilator
• Change over system open circuit or close circuit
• Emergency Oxygen flush valve at table level to give 35-60 litre/min for emergencies.
• Cylinder yokes: Pin indexed yokes two each of oxygen & nitrous oxide a 50 mm diameter, colour coded gauges fitted at convenient angle for better visibility & clarity.
• High efficiency regulators for reliability two each for O₂ & N₂O
• Vaporizer, Halothane / Isoflurane / Sevoflurane

Technical Specifications

• Storage Space: Three spacious drawers to hold essential anesthesia kit and accessories.
• Castors: Large roller bearing anti-static castors with front brakes.
• Electronic gas mixing with electronic Hypoxia guard.
• Audio Visual alarm for failure.
• Electronic and mechanical Flush 30-70 Lpm Flow.
• System pressure relief at 125 cm.
• Cylinder Yokes: Color coded gas specific (pin indexed) yokes with sliding stainless steel clamping bars for easy handling.
• Holding 1 (One) each for and , 5 Ltr water capacity cylinders.
• Non-return / Pressure Relief Valve: Minimises risk of back flow of gases, blows off when pressure exceeds 125 cm.
• Oxygen Flush: Electronic and mechanical flush 30-70 LPM flow.
• Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22 & 15 mm connections.
• Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets one each for and Air.
• I n c a s e o f drop in piped gas pressure the pin index cylinders take over automatically.
• Hypoxia Guard: Electronic/ Digital Hypoxia guard.
• Gas Mixing: Electronic flowmeter for the graphical representation of and Air.
• Selectatec Brackets: Twin Selectatec Block.
• Breathing Circuits: Bains Circuit & Circle Absorber Y-Circuit provided as standard.
