DR-3001 DOUBLE BEAM MICROPROCESSOR XENON FLASH LAMP SPECTROPHOTOMETER

Category	DR-B2
External Size (WDH)	13837752250 mm
Internal Size (WDH)	1210600660 mm
Tested Opening	Safety height 10″
Max Opening	470 mm
Airflow Volume (Exhaust)	100%: 1320 m³/h (776 cfm)
Front Window	Motorized;Two-layer laminated toughened glass ≤6mm, Anti-UV
Filter	ULPA,99.9995% efficiency at 0.12μm (02), filter life indicator
Filter Guard Type	Aluminum alloy frame
Noise	NSF 49 ≤60 dB
Illumination	≥1000 Lux
Socket	2, Total consumption ≤500W
Display	Touch screen
Tap	Water tap1, Gas tap1
Power Supply	AC220V,50/ 60Hz
Consumption	400W
Alarm	Abnormal airflow velocity; Filter replacement; Front window at unsafe height
Blower	One ECM motor, 230V AC; Speed adjustable, high efficiency and low power consumption
Material	Working area: 304 stainless steel Frame,Decorative Plate: cold-rolled steel with anti- bacteria powder coating
UV Lamp	30W
Germicidal UV Lamp	Emission of 253.7 nanometers for most efficient decontamination
Certification	NSF 49
Illuminating Lamp	LED lamp, 20W*2
Standard Accessory	LED lamp2, UV lamp2, Base stand, SS water tap1, Gas tap1, Drain valve, Waterproof socket*2
Optional Accessory	Armrest, Airflow tester, Formalin fumigation sterilizer, Infrared sterilizer, exhaust duct
Package Size (WDH)	154010801900 mm
Gross Weight	340 kg

TECHNICAL PARAMETERS:

Parameter	DR-04WB	DR-06WB
Column	2 rows 4 holes	2 rows 6 holes
Temp. range	Rt+5~100℃
Temp. Resolution Ratio	0.1℃
Temp. Motion	±0.5℃
Temp. Uniformity	±1℃
Water sink	Stainless steel, surface electrolysis treatment
Outer shell	Cold rolled steel plate, surface electrostatic powder spray.
Heater	Stainless steel U-type heating tube
Power rating	1200 W
Temp. control mode	PID Controller
Timer	0 – 999 min（with timing function）
Timing function	Timing function, auto stop feature
Program	Optional: multi-section program control
Additional function	Deviation correction, menu key lock, power failure back-up, power-off parameter memory, PID-Tunable control
Sensor	Thermal resistor
Safety device	Over-temperature alarm, short-circuit protection.
Inner Chamber size(WLH)	305 x 305 x 130 mm	305 x 470 x 130 mm
Packing size (WLH)	415 x 415 x 275 mm	400 x 560 x 250 mm
Internal volume	12 L	18.6 L
Cover number per hole	∅120 mm
Power Supply 50/60Hz	220V, 50/60 Hz
Weight	6.5 kg	8 kg

Parameter	Specification	Feature	Description
★ Light Source	Xenon Flash Lamp	★ Xenon Flash Lamp	High Quality Flashing Xenon Lamp which can start to test directly without preheating.
★ Wavelength Range	190 nm–1100 nm	★ Powerful Functions	Photometric Measurement, Quantitative Measurement, Kinetics, Spectrum Scan, DNA/Protein Test, Multi-Wavelength Test, etc.
★ Spectral Bandwidth	1 nm	★ Massive Memory	In-house massive memory capable of saving up to 1024M for test data and working curves.
★ Photometric Range	0–200%T, 0.3–3A, 0–9999C (0–9999F)	★ USB Storage	USB port supports data transfer and easy export to Excel for further processing, analysis, and storage.
★ Display	7” TFT Color Screen	★ Large Sample Chamber	Accommodates 5–100 mm cuvettes of all kinds (at extra cost).
★ Detector	Imported Silicon Photodiode	★ Optional Accessories	Extensive accessories are optional, including a Peltier/Sipper System and 21 CFR compliant software, etc.
★ Measuring Mode	Absorbance, Transmittance, Reflectance, Concentration	★ Installation / Demonstration	Online installation/demonstration is provided free of cost.
★ Basic / Advanced Modes	Basic Mode, Quantitative, Kinetics, Multi-wavelength, Wavelength Scan, DNA / Protein Test	★ Video Support	Demonstration/installation video CD is provided free of cost.
★ Accessories	Choice of 3 Pin Power Cord / Dust Cover Supplied	★ Availability	Available On Order
★ Quality Control	Three Stages of Quality Checking before Dispatch	★ Warranty / Tax	1 Year Warranty; GST Extra
★ Software	CFR Software Available At Extra Cost

Item Name	CO2 Incubator
Model No.	DR-CO2-80UV	DR-CO2-80	DR-CO2-80+	DR-CO2-180UV	DR-CO2-180	DR-CO2-180+
Sterilization	UV	140°C	180°C	UV	140°C	180°C
Volume	80L	80L	80L	180L	180L	180L
Microprocessor-based controller	Proprietary algorithm to control CO2 and temperature
Display	LCD touch display
Temp control range	Ambient +5°C- 60°C
Temp stability	±0.1°C
Temp field uniformity	±0.3°C (at 37°C )
Timer function	0 – 999hr 59 min.
CO2 measurement principle	Infrared (IR) detection
CO2 control range	0-20%
CO2 display resolution	0.10%
CO2 supply	0.05~0.1MPa is recommended
Relative Humidity	Ambient humidity ~95% at 37°C
HEPA filtration	HEPA filters at the gas inlet, ISO 5 level, 5 minutes
Temperature recovery time	≤10 min (open door 30sec room temperature 25°C set value 37°C)
O2 concentration recovery time	≤5 min (open the door 30sec set value 5%)
MOC	The inner chamber is made up of stainless steel and outer chamber with MS with powder coating
Light	Florescent light
Historical data storage	250,000 messages
Data export interface	USB interface
Scalability	Up to 2 units can be stacked.
Working environment temperature	18~30°C
Power supply	230V±10%, 50~60Hz
Inner Dimensions (L x D x H) mm	450x450x450			550x600x600
Outer Dimensions (L x D x H) mm	650x650x750			750x800x850

Chamber design	Round and Rectangular
Vacuum range	Up to -760 mmHg
Temperature range	Ambient+5°C to 150°C (Optional 200ºC)
Temperature sensor	PT100
Temperature controller	Digital PID controller Display of SV & PV
Inner chamber	Hermetically welded stainless steel 304 sheet
External cabinet	Powder coated GI sheet
Door	Solid door with clamp & toughened glass window
Gasket	High temperature silicon gasket
Shelves	Removable SS shelves
Vacuum fittings	Vacuum valve / exhaust valves (Rubber hose)
Standard fittings	Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump
Power supply	220 Volts 50Hz
Optional	KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump
