₹269,500.00 Original price was: ₹269,500.00.₹245,000.00Current price is: ₹245,000.00.
Melting Point Apparatus – Specifications & Characteristics
Specifications
| Parameter | Specification |
| Measuring range | Ambient ~ 400°C |
| Measuring mode | Auto |
| Measuring methods | 8 |
| Resolution | 0.1°C |
| Linear heating-up rate | 0.1°C / min ~ 20°C / min |
| Accuracy | ≤200°C: ±0.4°C; >200°C: ±0.7°C |
| Repeatability | 0.3°C (heating rate: 1.0°C/min) |
| Linear heating rate error | ±10% |
| Number of capillary | 1 |
| Capillary dimensions | Outer diameter: φ1.4mm; Inner diameter: φ1.0mm; Length: 90mm |
| Height of sample | 3mm |
| Data storage | 1000 set |
| Display | 7 inch touch LCD |
| Printer (Thermal) | Optional accessory |
| Interface | Rs232, USB |
| Power supply | 220VAC, 50Hz, 100W |
| Package Dimension | 580mm × 445mm × 320mm |
| Weight (Gross) | 7.5kg |
Characteristics
• To be used in production of medicines, dye-stuffs, perfumes and other organic crystal substances.
• Use PID & PWM to control the temperature.
• Automatically records the melting curve.
• Calculate average value of initial and final melting points automatically.
• Equipped with clock function.
• Can connect to a computer for data transferring.
Warranty: 1 year
| Shaker Speed (20 – 250 RPM) (350,400 & 500 OPTIONAL) | |
|---|---|
| Orbit Diameter | ø 25 mm |
| Accuracy | ± 2% of maximum speed |
| Temperature range | 5˚C above RT to 60˚C & with cooling 5°C-60°C (Customize temperature options available) |
| Resolution | 0.1°C |
| Temp. accuracy | ± 0.3˚C |
| Power supply | 230V ± 10%, 50Hz |
| Flasks | 12X12 | 16X16 | 18X18 | 24X24 |
| 50ml | 19 | 40 | 45 | 60 |
| 100ml | 12 | 16 | 18 | 24 |
| 250ml | 9 | 12 | 16 | 24 |
| 500ml | 4 | 6 | 8 | 10 |
| 1000ml | 2 | 3 | 3 | 5 |
| 2000ml | 1 | 2 | 2 | 4 |
TECHNICAL PARAMETERS
Volume [L]: 220
Temp. Range [°C]: +5 to 60
Temp. Resolution [°C]: 0.1
Temp. Fluctuation at 37°C [°C]: ±0.5
Temp. Uniformity at 37°C [°C]: ±1
Rotation Rate [rpm]: 1~300
Rotation Accuracy [rpm]: ±1
Vibration Amplitude [mm]: Ø25
Timer Range [h]: 0~999
Number of Trays [pc]: 1 included ( 2 optional)
Power Supply [V, Hz]: 220, 50/60
Internal Dimensions W×D×H [mm]: 600x600x600
Housing Dimensions W×D×H [mm]: 755×870×1310
Tray Size W×D [mm]: 595x595mm
Standard Configuration [pcxml]: 16×250/500 or 9×1000 ml or 4×2000 ml
Net Weight [kg]: 220
