DR Labs DR- PH-100 is an easy to use benchtop pH meter designed for daily testing & quality control. This meter has clear & bright back light display that shows the measured value, temperature, mode indicators. Features like 3 point push-button calibrations, automatic buffer recognition, electrode slope display, automatic temperature compensation make this equipment a clear favorite of all.
SALIENT FEATURES:
• Large back light LCD display shows mode indicator, ph value, temperature
•Up to 3 point push -button calibration with automatic buffer recognition
•Selectable pH buffer standards and temperature units.
•Automatically calculates and display electrode slope after calibration
•Automatic temperature compensation (ATC) ensure highly accurate measurements over the entire range.
•Automatic endpoint function freezes the stable measured value
•Setup menu allows setting the pH buffer group, number of calibration points, temperature unit, auto-power off, etc.
•Reset function can resumes all setting to factory default value
FEW APPLICATIONS:
• Research & Education
• Water & effluent control
• Environmental &
Agricultural monitoring
• Drinking water
• All other industrial
application
STANDARD ACCESSORIES:
• pH Meter
• pH Electrode
• Temp. Probe
• pH Buffer
• Electrode Stand
• Adapter
• Instruction Manual
| Model | DR-PH-100 |
|---|---|
| Make | DR Labs |
| pH Range | -2 to 16.00 pH |
| pH Resolution | 0.01 pH |
| pH Accuracy | ± 0.01 pH |
| Calibration Points | up to 3 points |
| pH Buffer options | USA (pH 4.01, 7.00, 10.01) or NIST |
| ORP Range (mV) | ± 1999 mV |
| ORP Accuracy(mV) | ± 1% FS ±1 digit |
| ORP Resolution(mV) | 1 mV |
| Temp. Range | 0 to 105°C |
| Temp. Accuracy | ± 0.5°C |
| Temp. Resolution | 0.1°C |
| Temp. Compensation | 0 to 100°C, Manual/Automatic |
| Hold Function | Available |
| Auto Off function | Available |
| Electrode Connector | BNC |
| Display | Backlight LCD |
| Dimensions & Weight | 210 x 205 x 75 mm & 1.5 kg |
SPECIFICATIONS:
| Temperature range | -10° C to -40°C |
|---|---|
| Temperature accuracy | ±0.5°C |
| Temperature Uniformity | ±0.1°C |
| Temperature controller | Dual display PID controller |
| Temperature sensor | PT100 |
| Inner chamber | SS 304 |
| External cabinet | Powder coated GI sheet |
| Insulation | Glass wool |
| Door | Insulated door Mechanical latch / clamp |
| Heaters | Resistance wire heaters |
| Shelves | SS wire mesh (removable) |
| Standard fittings | Mains on/off switch Load Indicator Fan on/off switch |
| Power supply | 220 Volts 50Hz |
| Optional | GMP construction (Inner & outer SS304) PLC + HMI controller w/ USB interface 21 CFR Part 11software Data logger w/ USB interface Thermal printer Inner chamber LED light |
SPECIFICATIONS:
| Model No. | DR-800D |
| Center Max. Temp. | 825°C |
| Low Level Temp. | 480°C |
| Heating Speed | 20min (to max. temp.) |
| Max. Sterilize Diameter | Φ35mm |
| Heating Element Length | 100mm |
| Adjustable Angle | 75°~120° |
| Voltage | AC 220V / AC 110V, 50/60Hz |
| Power | 400W |
| Fuse | 250V, 3A/5A, Ф5×20 |
| Dimension (WxDxH) | 92 x 101 x 170mm |
| Net Weight | 1.1kg |
SPECIFICATIONS:
| Temperature Range | 5°C to 60°C |
| Temperature accuracy | ±1°C |
| Temperature controller |
|
| Humidity Range | 40% to 95% RH |
| Humidity accuracy | ±3% RH |
| Humidity controller |
|
| Chamber Illumination | Fluorescent white light |
| Construction | Double walled |
| Insulation | PUF insulation |
| Exterior | Powder coated GI sheet |
| Interior | Stainless steel 304 |
| Door | Solid insulated door with lock and key |
| Inner door | Glass door fitted in steel frame |
| Shelves / trays | 2 to 5 steel wire mesh trays (height adjustable) |
| Air Circulation | Axial fan / blower |
| Refrigeration | CFC Free compressor with condenser, motor and relay complete unit |
| Humidity system |
|
| Optional |
|
| Volume (Liters) | Inner Chamber size (mm) | Trays | |
| 200 Liters | 600 x 600 x 600 | 2 | |
| 324 Liters | 600 x 600 x 900 | 2 | |
| 450 Liters | 600 x 600 x 1250 | 3 | |
| 600 Liters | 600 x 800 x 1250 | 3 | |
| 800 Liters | 800 x 800 x 1250 | 4 | |
| 1000 Liters | 800 x 800 x 1570 | 4 |
| Model | DR-RCB-6 | DR-RCB-12 |
|---|---|---|
| Make | DR Labs | DR Labs |
| Temp. Control Range | -20°C ~ 100°C | -20°C ~ 100°C |
| Temp. Resolution | 0.01°C | 0.01°C |
| Temp. Accuracy | ±0.05°C | ±0.05°C |
| Temp. Control | Microprocessor PID | Microprocessor PID |
| Display | LCD | LCD |
| Refrigeration Model | Air cooled refrigeration through compressor | Air cooled refrigeration through compressor |
| Refrigerant | R134A | R134A |
| Pump Circulation | Internal & External | Internal & External |
| Temp. Sensor | PT-100 | Â PT-100 |
| Pump Flow Rate | 6L/min | 6L/min |
| Tank Capacity | 6L | 12 L |
| Tank Size | 250 x 200 x 150 mm | 300 x 250 x 200 mm |
| Bath Opening | 180 x 140 mm | 235 x 160 mm |
| Bath Depth | 150 mm | 200 mm |
| Power Supply | AC 220 V / 50 Hz | AC 220 V / 50 Hz |
| Dimensions | 320 x 370 x 655 mm | 320 x 370 x 765 mm |
| Packing Dimensions & Weight | 530 x 450 x 800 mm & 44 kgs | 530 x 450 x 900 mm & 50 kgs |
