₹214,500.00 Original price was: ₹214,500.00.₹195,000.00Current price is: ₹195,000.00.
| Features
★ Single-chip microcomputer control, LCD Screen (128 X 64 Dots) ★ Large LCD display can display multiple sets of data. ★ Large memory space can store multiple sets of data and curve. ★ Auto zero, 100% adjustment function. ★ Auto wavelength adjustment. ★ Auto filter changing, large sample holder (5mm-100mm). ★ Direct input by K, B factor for quantitative measurement standard curve. |
Technical Specification ★ Wavelength Range 190~1100nm ★ Band Width 2nm ★ Wavelength Accuracy +0.5nm ★ Wavelength Repeatability <0.2nm ★ Photometric Accuracy +0.3%T ★ Photometric Repeatability 0.1%T ★ Stray Light NaI, 360nm, NaNO2 ★ Stability 0.001A/h@500nm ★ Photometric Mode T,A,C,E ★ Wavelength Setting Automatic ★ Power Supply : AC~220V, 50Hz ★ Three Stages of Quality Check before Dispatch ★ Online Installation/ Demonstration Provide free of cost ★ Demonstration / Installation Video CD are Provide at |
| Item Name | CO2 Incubator | |||||
| Model No. | DR-CO2-80UV | DR-CO2-80 | DR-CO2-80+ | DR-CO2-180UV | DR-CO2-180 | DR-CO2-180+ |
| Sterilization | UV | 140°C | 180°C | UV | 140°C | 180°C |
| Volume | 80L | 80L | 80L | 180L | 180L | 180L |
| Microprocessor-based controller | Proprietary algorithm to control CO2 and temperature | |||||
| Display | LCD touch display | |||||
| Temp control range | Ambient +5°C- 60°C | |||||
| Temp stability | ±0.1°C | |||||
| Temp field uniformity | ±0.3°C (at 37°C ) | |||||
| Timer function | 0 – 999hr 59 min. | |||||
| CO2 measurement principle | Infrared (IR) detection | |||||
| CO2 control range | 0-20% | |||||
| CO2 display resolution | 0.10% | |||||
| CO2 supply | 0.05~0.1MPa is recommended | |||||
| Relative Humidity | Ambient humidity ~95% at 37°C | |||||
| HEPA filtration | HEPA filters at the gas inlet, ISO 5 level, 5 minutes | |||||
| Temperature recovery time | ≤10 min (open door 30sec room temperature 25°C set value 37°C) | |||||
| O2 concentration recovery time | ≤5 min (open the door 30sec set value 5%) | |||||
| MOC | The inner chamber is made up of stainless steel and outer chamber with MS with powder coating | |||||
| Light | Florescent light | |||||
| Historical data storage | 250,000 messages | |||||
| Data export interface | USB interface | |||||
| Scalability | Up to 2 units can be stacked. | |||||
| Working environment temperature | 18~30°C | |||||
| Power supply | 230V±10%, 50~60Hz | |||||
| Inner Dimensions (L x D x H) mm | 450x450x450 | 550x600x600 | ||||
| Outer Dimensions (L x D x H) mm | 650x650x750 | 750x800x850 | ||||
| Air flow direction | Vertical and Horizontal |
|---|---|
| Air cleanliness | Class 100 |
| Construction | SS / Powder coated MS / GI sheet/ wooden with 18 gauge ss. |
| Sash (front door) | Manual/ Motorized sliding type (Acrylic transparent and tiffin glass) |
| Side panels | Acrylic /polycarbonate / SS |
| Air velocity | 0.4 m/s to 0.6 m/s/ 0.45m/sec |
| Illumination | Fluorescent or LED light/ UV light (800lux, glare-free) |
| Noise level | 65 ±5 dB |
| Power supply | 220 volts / 50 Hz |
| Air filtration |
|
| Air filtration |
|
| Optional |
|
| Chamber design | Round and Rectangular |
|---|---|
| Vacuum range | Up to -760 mmHg |
| Temperature range | Ambient+5°C to 150°C (Optional 200ºC) |
| Temperature sensor | PT100 |
| Temperature controller | Digital PID controller Display of SV & PV |
| Inner chamber | Hermetically welded stainless steel 304 sheet |
| External cabinet | Powder coated GI sheet |
| Door | Solid door with clamp & toughened glass window |
| Gasket | High temperature silicon gasket |
| Shelves | Removable SS shelves |
| Vacuum fittings | Vacuum valve / exhaust valves (Rubber hose) |
| Standard fittings | Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump |
| Power supply | 220 Volts 50Hz |
| Optional | KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump |
