MICROWAVE DIGESTION SYSTEM

Sale!

Product Code: DR-MW12

Categories: ANALYTICAL INSTRUMENTS, LABORATORY EQUIPMENTS

Original price was: ₹1,754,500.00.Current price is: ₹1,595,000.00.

Microwave Digestion System – 12-Position Technical Specifications

Specification	Details
Vessel quantity	12
Temperature monitoring	Contactless IR sensor temperature monitoring; each vessel temperature controlled
Temperature control range	50–400°C
Maximum working temperature	250°C
Temperature accuracy	±0.1°C
Pressure monitoring	Contactless sensor pressure monitoring; each vessel pressure controlled
Pressure control range	0–15 MPa
Maximum working pressure	6 MPa
Pressure accuracy	±0.01 MPa
Vessel volume	100 mL
Sample vessel material	Imported TFM
Protection vessel material	PEEK + Glass Fiber
Display	7-inch color touch screen
Rotation	One direction, 360° continuous rotating

Features

• Compatible with 12-position sample rotor.

• Imported contactless IR sensor and pressure sensor provide real-time display of sample solution temperature and pressure in each vessel and show T&P scanning curves.

• No consumables such as bursting discs or sealing cups, helping reduce maintenance cost.

• 7-inch smart touch screen with a user-friendly UI.

• Pre-installed multiple international application methods; users can edit, modify, and delete the methods.

• 316L stainless-steel explosion-proof cavity with multi-layer anti-corrosive and heat-resistant coatings, extending service life and improving operational safety.

• High-power turbulent air cooling design for fast cooling.

• Professional electromagnetic protection design compatible with high-level microwave leakage protection standards.

Related products

PCR CABINET /HOOD

ir flow direction	Vertical
Air cleanliness	Class 100
Construction	SS / Powder coated MS / GI sheet/ wooden
Air flow direction	Vertical
Sash (front door)	Manual sliding type (Acrylic transparent)
Side panels	Acrylic / polycarbonate / SS
Air velocity	0.45 m/s to 0.65 m/s
Illumination	Fluorescent or LED light
Noise level	65 ±5 dB
Power supply	220 volts / 50 Hz
Air filtration	Pre-Filter – 10 microns (washable) HEPA filter (0.3 Microns)
Standard fittings	Air / gas cock, Mains on/off switch, Light on/off switch UV Light on/off switch, Blower on/off switch
Optional	Motorized sliding door LCD display for velocity, time & lamp on/off UV Germicidal lamp UV Hour meter Magnehelic gauge Extra power outlet switch Foot rest Levelling legs for stand DOP HEPA filter testing

STABILITY / HUMIDITY CHAMBER

SPECIFICATIONS:

Temperature Range	5°C to 60°C
Temperature accuracy	±1°C
Temperature controller	Microprocessor PID controller Display of SV & PV Low / High buzzer
Humidity Range	40% to 95% RH
Humidity accuracy	±3% RH
Humidity controller	Microprocessor PID controller Display of SV & PV Low / High buzzer
Chamber Illumination	Fluorescent white light
Construction	Double walled
Insulation	PUF insulation
Exterior	Powder coated GI sheet
Interior	Stainless steel 304
Door	Solid insulated door with lock and key
Inner door	Glass door fitted in steel frame
Shelves / trays	2 to 5 steel wire mesh trays (height adjustable)
Air Circulation	Axial fan / blower
Refrigeration	CFC Free compressor with condenser, motor and relay complete unit
Humidity system	SS tank with heater Low water buzzer Auto filling water system
Optional	Stainless steel exterior (GMP) PLC based HMI controller w/ USB interface RS 485 interface 21 CFR part 11 software UV light Storage racks Validation port Caster wheels with brake IQ, OQ and PQ documents

Volume (Liters)	Inner Chamber size (mm)	Trays
200 Liters	600 x 600 x 600	2
324 Liters	600 x 600 x 900	2
450 Liters	600 x 600 x 1250	3
600 Liters	600 x 800 x 1250	3
800 Liters	800 x 800 x 1250	4
1000 Liters	800 x 800 x 1570	4

SEED GERMINATOR CHAMBER

Temperature range	5°C to 60°C
Temperature controller	Digital PID controller
Temperature accuracy	±1%
Temperature sensor	PT-100
Humidity range	50% to 90% RH
Humidity controller	Digital PID controller
Humidity accuracy	±3%
Light	150-170 micromole/m2/sec
Light timer	24×7 weekly digital timer
Construction	Double walled
Exterior	Mild steel powder coated
Interior	Stainless steel 304
Outer door	Single or double solid doors with lock & key
Inner door	Glass door to view samples
Shelves	3 to 12 (Height adjustable)
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz

SIZE:

Model

Dimensions (mm)

Volume (Litres)

Volume (Cu. Ft.)

DR-SGC171

505 x 415 x 830

171

DR-SGC209

600 x 550 x 910

300

Temperature range	5°C to 60°C
Temperature controller	Digital PID controller
Temperature accuracy	±1%
Temperature sensor	PT-100
Humidity range	50% to 90% RH
Humidity controller	Digital PID controller
Humidity accuracy	±3%
Light	150-170 micromole/m2/sec
Light timer	24×7 weekly digital timer
Construction	Double walled
Exterior	Mild steel powder coated
Interior	Stainless steel 304
Outer door	Single or double solid doors with lock & key
Inner door	Glass door to view samples
Shelves	3 to 12 (Height adjustable)
Safety	Audio / visual alarm for temperature deviation
Optional	Exterior made of stainless steel 304 / 316 PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels
Power supply	220 Volts / 50 Hz

STANDARD SIZE:

Model	Dimensions (mm)	Volume (Litres)	Volume (Cu. Ft.)
DR-SGC171	505 x 415 x 830	171	6
DR-SGC209	600 x 550 x 910	300	10
DR-SGC340	650 x 580 x 900	340	12
DR-SGC400	700 x 640 x 900	400	14
DR-SGC580	775 x 775 x 970	580	20

DR-SGC340

650 x 580 x 900

340

DR-SGC400

700 x 640 x 900

400

DR-SGC580

775 x 775 x 970

580

HORIZONTAL AUTOCLAVE
