₹544,500.00 Original price was: ₹544,500.00.₹495,000.00Current price is: ₹495,000.00.
Specifications:
| ★ Measuring mode | Optical Rotation, Specific Rotation, Concentration, International Sugar Scale |
| ★ Light source | LED + interference filter |
| ★ Wavelength | 589nm |
| ★ Measuring range | ±45°(OR) ; ±120°Z (ISS) |
| ★ Accuracy | ±0.01° (-15°≤OR≤+15°) ±0.02° (OR<-15° or OR>+15°) |
| ★ Resolution | 0.001°(OR) ; 0.01°Z (ISS) |
| ★ Repeatability | 0.002 °(OR) |
| ★ Min. transmission | 1% |
| ★ Temp. control range | 15-30°C |
| ★ Temp. accuracy | ±0.5°C |
| ★ Display | 7 inch color touch LCD |
| ★ Interface | Rs232, USB |
| ★ Test Tube | 100mm 200mm (regular) 100mm(temp control) |
| ★ Power supply | AC~220V, 50Hz |
| ★ Package dimensions | 820mm×500mm×510mm |
| ★ Weight (Gross) | 37kg |
Characteristics
★ Need not preheat when turning on.
★ Automatically retest 6 times and calculate the average and room mean square, can measure dark samples.
★ Available to measure dark-colored sample.
★ Peltier principle to control the temperature
★ Color touch screen.
★ Extra Test Tube 100/200mm @Rs 2500/-
1 YEAR WARRANTY
(GST Extra)
| Model no. | DR -80 |
|---|---|
| Volume | 450 L |
| Temperature | -40 TO -80℃ |
| Insulation thickness | 150mm |
| Cooling type | Direct cooling |
| Electric protection | I/B |
| Refrigerant | Mixed |
| Interior dimension | 552x635x1142mm |
| Consumption | 9.8kW. h/24h |
| Power | 1000W |
| Power Supply | 220V/50Hz |
| Climate class | N |
| Alarm type | Sound/ light |
| Exterior dimension | 855x965x1865mm |
| Package dimension | 960x1030x2030mm |
| Net weight | 205 kg |
| Gross weight | 255 kg |
| Optional function | Printer & recorder |
| Chamber design | Round and Rectangular |
|---|---|
| Vacuum range | Up to -760 mmHg |
| Temperature range | Ambient+5°C to 150°C (Optional 200ºC) |
| Temperature sensor | PT100 |
| Temperature controller | Digital PID controller Display of SV & PV |
| Inner chamber | Hermetically welded stainless steel 304 sheet |
| External cabinet | Powder coated GI sheet |
| Door | Solid door with clamp & toughened glass window |
| Gasket | High temperature silicon gasket |
| Shelves | Removable SS shelves |
| Vacuum fittings | Vacuum valve / exhaust valves (Rubber hose) |
| Standard fittings | Mains on/off switch Vacuum pump on/off switch Electric socket for vacuum pump |
| Power supply | 220 Volts 50Hz |
| Optional | KF25 flange vacuum connection 21 CFR compliance software Temperature up to 250°C All SS 304 construction (GMP) Digital vacuum control through solenoid valves PLC + HMI controller with USB interface Diaphragm valves for inert gas Timer 99 hours 59 min Oil-free vacuum pump |
| Construction | Economy Model | Double Walled Model | Triple Walled Model |
|---|---|---|---|
| MOC Exterior | Painted MS sheet | SS 304 (mirror finish) | SS 304 (mirror finish) |
| No. of walls | Two | Two | Three |
| Lid | Polished MS | SS 304 | SS 304 |
| Interior | SS 304 with silicon gasket | ||
| Working Pressure | 15-30 psi | ||
| Working Temp. | 121°C to 134°C | ||
| Controller | Auto set to 15psi & 121°C | ||
| Pressure display | Analogue dial gauge | ||
| Timer | Mechanical timer | ||
| Programmable | Programmable automatic start timer | ||
| Hydraulic tested | Hydraulically Tested up to 40 psi (ASME Guideline) | ||
| Lick lock | Single hand easy lock system for operating and closing | ||
| Program for heating sterilization, exhaust, warming and completion. | |||
| Basket | Stainless steel basket | Stainless steel basket | Not Required |
| Power supply | 220 Volts 50Hz | ||
| Standard Fittings | Low water indicator; Automatic pressure switch; Pedal lifting device Steam release valve; Water outlet valve; Spring loaded safety valve Power cable with three pin tops | ||
| Optional Accessories |
|
||
