₹24,750.00 Original price was: ₹24,750.00.₹22,500.00Current price is: ₹22,500.00.
Features
• Abundant output of approximately 4 litres/hour of distilled water with a 3 kW chromium-plated heater.
• Horizontal borosilicate glass boiler (Pyrex brand borosilicate glass).
• Efficient condenser; distillate temperature approximately 25°C–40°C at an ambient room temperature of 30°C.
• Provision for wall mounting.
• Ideal for general laboratory use and capable of producing pyrogen-free water.
Technical Specifications
| Parameter | Specification |
| Model | LPH-4 |
| Dimensions (W × D × H) | 50 cm × 15 cm × 45 cm |
| Weight | 6 kg approx. |
| Electrical | 220/240 V, 50/60 Hz, Single Phase |
| Power | 3 kW Heater |
| Water Supply | Minimum flow rate 1 litre/min |
| Minimum Pressure | 3 p.s.i. (0.2 × 10⁵ N/m²) |
| Output | 4 L/hr |
| Conductivity (using raw water) | 3.0–4.0 µS/cm |
| Conductivity (using raw water) | 1.5–2.0 µS/cm |
| pH | 5.5–6.0 |
| pH / Water Quality | Pyrogen Free |
Spares
• Lasany LPH / LB: Boiler
• Lasany LPH / LH: 3 kW Heater
• Lasany LPH / LH: Condenser
Packing Information
• Packing: 7 Ply carton with PUF packing
• Dimensions: 50 × 47 × 46 cm
• Gross Weight: 12.00 kg approx.
Construction
• Stand is powder coated for long rust-free operation.
• 3 kW chromium-plated heater fitted with a thermostat that shuts off automatically in case of water-supply failure.
• Boiler and condenser are designed for high efficiency and provided with threading for easy plumbing of the condenser.
• Boiler is provided with Teflon screw cock for inside cleaning of the boiler.
• All plumbing connections to the equipment are made via screw-thread connectors.
Model Availability
Model Basic / pH4-XL (also available on special request).
Category
Laboratory Equipment → Water Distillation U
TECHNICAL PARAMETERS
Volume [L]: 220
Temp. Range [°C]: +5 to 60
Temp. Resolution [°C]: 0.1
Temp. Fluctuation at 37°C [°C]: ±0.5
Temp. Uniformity at 37°C [°C]: ±1
Rotation Rate [rpm]: 1~300
Rotation Accuracy [rpm]: ±1
Vibration Amplitude [mm]: Ø25
Timer Range [h]: 0~999
Number of Trays [pc]: 1 included ( 2 optional)
Power Supply [V, Hz]: 220, 50/60
Internal Dimensions W×D×H [mm]: 600x600x600
Housing Dimensions W×D×H [mm]: 755×870×1310
Tray Size W×D [mm]: 595x595mm
Standard Configuration [pcxml]: 16×250/500 or 9×1000 ml or 4×2000 ml
Net Weight [kg]: 220
| Parameters | Specifications |
|---|---|
| Temperature range | Lights Off: 5°C to 60°C; Light ON: 10°C to 60°C |
| Temperature controller | Digital PID controller with SV & PV values |
| Temperature accuracy | ±1% |
| Humidity | 50% to 90% |
| Humidity controller | Digital PID controller with SV & PV values |
| Humidity accuracy | ±3% |
| Illumination | 3 sides illumination with detachable LED lights(10000 LUX or 23000 LUX) |
| Light timer | 24×7 weekly digital timer |
| Shelves | Stainless steel or chrome plated (Height adjustable) |
| Humidity system | SS boiler tank with immersion heater and automatic water replenishment by external tank |
| Safety | Audio / visual alarm for temperature deviation |
| Optional | Exterior made of stainless steel 304 / 316 White painted steel inner walls Door open alarm Plant growth racks UV lamp PLC with HMI interface Data logger with USB interface Password protection for controller Caster wheels |
| Power supply | 220 Volts / 50 Hz |
| DR-150PGC | 800 x 500 x 380 | 150 L |
| DR-250PGC | 550 x 450 x 1000 | 250 L |
| DR-350PGC | 550 x 550 x 1200 | 350 L |
| DR-450PGC | 800 x 600 x 1250 | 600 L |
| DR-800PGC | 1120 x 600 x 1200 | 800 L |
| DR-1000PGC | 1150 x 670 x 1300 | 1000 L |
